Toshiba Part #/MPN: MG07SCA12TEY
DiscTech Item #: TOS-MG07SCA12TEY-BN-OE-DEL
- Brand New
- Warranty:1 Year DiscTech
- Low Stock:Call for ETA
Enterprise Grade
Capacity: 12TB
Speed: 7.2K RPM
Interface Types: SAS
Form Factor: 3.5" LFF Hard Drive
Sector Size: 512 / 512e
Average Seek Time: 242
Electrical Interface: SAS-3 12Gbps
On-Board Cache: 256MB
Dell DK7C9 / Toshiba MG07SCA12TEY 12TB 3.5-Inch LFF 12Gbps 7.2K RPM 512e MG07SCA Series Enterprise SIE SAS Hard Drive - Brand New
Toshiba MG07SCA12TE 12TB / 12000 3.5” LFF / Large Form Factor 12.0 Gb/s 7200 RPM 512e / 512 Emulation MG07SCA Series Enterprise SIE / Sanitize Instant Erase SAS / Serial Attached SCSI HDD Hard Drive - Brand New
MG07SCA Series
Enterprise Capacity HDD
The MG07SCA Enterprise Capacity HDD series provide capacities up to 14 TB and 7,200 rpm performance, in a robust design engineered for near-line business-critical workloads.
The MG07SCA series utilize industry-standard 3.5-inch 26.1 mm height from factor and Advanced Format sector technologies helps enhance performance while also maintaining data integrity in the event of a sudden loss of power. Equipped with 12 Gbit/s SAS Interface, the Enterprise Capacity MG07SCA series help save rack space and reduce the footprint and operational burden of business critical servers and storage systems.
512e or 4Kn Advanced Format sector technology models are available. 4Kn models (MC07SCAxxxA/AY) offer optimum performance and compatibility with 4K-capable applications and operating environments. 512e (MC07SCAxxxA/AY) models are broadly supported today and also help provide support for legacy applications and operating environments that require 512 B sector lengths.
KEY FEATURES
- Industry Standard 3.5-inch 26.1 mm Height Form Factor
- Large Capacity (14 TB and 12 TB Models)
- 7,200 rpm Performance
- Dual-Port 12 Gbit/s SAS Interface
- MTTF of 2,500,000 hours
- 550 total TB Transferred per Year Workload Rating
- 4Kn or 512e Advanced Format Sector Technology
- Toshiba Persistent Write Cache Technology to help Maintain Data Integrity during Power-Loss Events
- Sanitize Instant Erase (SIE) option model
APPLICATIONS
- Engineered for Mid-line / Near-line Business Critical Workloads
- Tier 2 Business-Critical Servers and Storage Systems
- Servers Supporting Application Workloads that Benefit form High Capacity per Spindle
- Capacity-Optimized Data Center Storage Systems
- Object and File Storage Solutions
- Enterprise Data Protection and Tiered Storage Infrastructure
Alt MPNs: DK7C9 0DK7C9
Compatibility:
This drive is compatible with servers and arrays that accept 3.5in x 1.0in SAS drives
Toshiba MG07ACA Series Enterprise Capacity HDD | |
---|---|
512 Emulation (512e), SIE Model# | MG07SCA12TEY |
SPECIFICATIONS | |
Sector Size | 512e Emulation (512e) |
Form Factor | 3.5-Inch |
Interface | SAS-3.3 |
Formatted Capacity | 12TB / 12,000GB |
Performance | Interface Speed Rotation Speed Buffer Size Maximum Sustained Data Transfer Speed (Typ) |
Logical Data Block Lenth | MG07SCAxxxE/EY (emulation) |
Supply Voltage | Allowable Voltage |
Power Consumption | Random Write / Read 4KB Q1 (Typ) Active Idle (Idle-A) |
Acoustics | Active Idle (Typ) |
ENVIRONMENTAL LIMITS | |
Ambient Temperature | Operating Non-Operating |
Relative Humidity | operating Non-Operating |
Altitude | Operating Non-Operating |
Shock | Operating Non-Operating |
Vibration | Operating Non-Operating |
RELIABILITY | |
MTTF | 2,500,000 hours |
Non-recoverable Error Rate | 10 error per 1016 bits read |
Load / Unload | 600,000 times |
Availability | 24 hours/day, 7 days/week |
Ratted Annual Workload (Total TB Transferred per Year, R/W) | 550 TB per year |
MECHANICAL SPECIFICATIONS | |
Width (Max) | 101.85 mm |
Height (Max) | 26.1 mm |
Length (Max) | 147.0 mm |
Weight (Max(Typ)) | 720 g / 1.59 lbs |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: DK7C9 0DK7C9
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Brand New
1 Year DiscTech Warranty
