Dell Enterprise DPD14 / Intel SSDSC2BA800G4R 800GB SATA 6Gb/s 2.5 MLC Write Intensive SSD


DiscTech Item #: INT-SSDSC2BA800G4R-NP-OE-DEL


Enterprise Grade

Capacity: 800GB

Speed: Solid State Memory

Interface Types: SATA

Form Factor: 2.5inx7mm Fits All laptops

Sector Size: 512 / 512e

Electrical Interface: SATA 600 - 6.0Gbps


SSD Endurance DWPD: Enterprise Write Intensive

Compatible Systems: Dell 13th Gen. R730/T630, Dell 12th Gen. R720/T620, Dell 11th Gen. R710/T610

Dell Enterprise DPD14 / Intel SSDSC2BA800G4R 800GB DC S3710 Series SATA III 6Gb/s 2.5 MLC Write Intensive 10-DWPD SSD  - New Pull OEM

Enterprise applications place a premium on performance, reliability, power consumption, and space. Unlike traditional hard disk drives, Intel Solid-State Drives have no moving parts, resulting in a quiet, cool storage solution that also offers significantly higher performance than traditional server drives. Imagine replacing up to 50 high-RPM hard disk drives with one Intel SATA Solid-State Drive in your servers handling the same server workload in less space, with no cooling requirements and lower power consumption. That space and power savings, for the same server workload, will translate into a tangible reduction in your TCO.

The Intel SATA Solid-State Drive (SSD) offers outstanding performance and reliability, delivering the highest IOPS per watt for servers, storage and high-end workstations. Intel Solid-State Drive has no moving parts, resulting in a quiet, cool storage solution that also offers significantly higher performance than traditional server drives.

DP/N: DPD14  0DPD14


This Solid State Disk (SSD) is compatible with all laptops and servers that support standard SATA interface.

Mfgr / SeriesIntel DC S3710
Intel Model NumberIntel SSDSC2BA800G4R
Dell Part NumberDPD14 0DPD14
InterfaceSAS 6Gb/s
Form Factor2.5"
Capacity800 GB
European Union Restriction of Hazardous SubstancesY
Sequential Read / Write

500 MB/s - 460 MB/s

Random Read / Write (100% Span)

75k IOPS / 36K IOPS

Latency Read / Write

50 µs / 65 µs

Power Active / Idle5.4W / 650mW
Vibration Operating / Non-Operating21.7 GRMS / 3.13 GRMS
Operating Temperature Range    0°C - 70°C
Endurance Rating10 drive writes / day for 5yrs
Uncorrectable Bit Error Rate (UBER)1 sector per 10^17 bits read
Interface    SATA 6Gb/s
Form Factor2.5"
EncryptionAES 256 bit encryption
ComponentsIntel NAND Flash Memory Multi-Level Cell (MLC) Technology

ROHS Compliant

Alternate MPNs: DPD14 0DPD14

Weight: 0.5 lb

Warranty: 1 Year DiscTech

New Pull

Condition Levels Explained

The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.
