Seagate Part #/MPN: ST4000NM0025
DiscTech Item #: SGT-ST4000NM0025-BN-OE-DEC
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Enterprise Grade
Capacity: 4TB
Speed: 7,200RPM
Interface Types: SAS Serial Attached SCSI
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps
On-Board Cache: 128MB
Alt MPN: V9M9K
For Compellent Arrays.
This SAS drive offers the world’s largest capacities in a 3.5-inch form factor. Build cost-effective maximum capacity storage solutions with enterprise-class, 7200-RPM drives in capacities up to 4TB, with a sixth-generation SAS interface for easy integration.
Additionally, Enterprise Capacity hard drives further power reductions with enhanced PowerChoice™ technology. Purpose-built for enterprise environments, the PowerChoice feature enables the T10-compliant power management standard, allowing organizations to tailor systems for optimal energy usage resulting in up to 90% more power savings. The drive provides enhanced error correction, super-parity and end-to-end SAS-based data integrity for accurate data storage each and every time. With its robust 7200-RPM performance, ramp load technology and a humidity sensor for optimum performance, it’s the perfect solution for maximizing your enterprise system availability. Powered by our multi-drive firmware and enhanced rotational vibration tolerance, this Enterprise Capacity drive can help to ensure consistent and reliable performance.
Compatibility:
This drive is compatible with any system that accepts 3.5" SAS 4TB 7.2K Drives with generic firmware.
For Compellent Arrays.
Product Specifications | |
| Interface | SAS 6 Gb/s |
Performance Specifications | |
| Rotational Speed | 7,200 RPM (nominal) |
| Cache | 256 MB |
| Transfer Rate, Max Ext (MB/s) | 600 MB/s |
| Sustained Data Rate OD | 226MB/s |
| Average Latency (ms) | 4.16 |
Reliability/Data Integrity | |
| Nonrecoverable Read Errors per Bits Read | 1 in 1015 |
| Annualized Failure Rate (AFR) | 0.44% |
| Physical Dimensions | |
| English | |
| Height | 1.028 Inches |
| Length | 5.787 Inches |
| Width | 4.01 Inches |
| Weight | 1.55 Lbs |
| Metric | |
| Height | 26.1 mm |
| Depth | 147 mm |
| Width | 101.85 mm |
| Weight | 0.705 kg |
| Environmental Specifications | |
| Shock | |
| Operating Shock (Read) | 70/40G (1ms /2 ms) |
| Non-operating Shock | 250/150G (1ms /2 ms) |
| Acoustics (belssound power) | |
| Idle Mode | 2.8 |
| Seek Mode 0 | 3.0 |
| Temperature (English) | |
| Operating | 41° F to 131° F |
| Non-operating | -40° F to 158° F |
| Temperature (Metric) | |
| Operating | 5° C to 60° C |
| Non-operating | -40° C to 70° C |
| Electrical Specifications | |
| Current Requirements | |
| Power Dissipation: | |
| Read/Write | 8.31 Watts |
| Idle | 7.25 Watts |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: V9M9K 0V9M9K
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
