Dell Equallogic 519NF / MW5KG / Toshiba PX04SRB384 3.84TB 2.5" SFF 12Gbps MLC Read Intensive SAS SSD
- Brand NewCondition Levels Explained
The product is brand new.
- In Stock:1Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 3.84TB |
| Speed: | Solid State |
| Interface Types: | SAS |
| Form Factor: | 2.5" SFF Server Drive |
| SSD Endurance DWPD: | Enterprise Read Intensive / RI |
| Electrical Interface: | SAS-3 12Gbps |
Description
Dell 519NF / MW5KG / Toshiba PX04SRB384 3.84TB 2.5" SFF 12Gbps MLC Read Intensive SAS Solid State Drive - Brand New
Dell 519NF / MW5KG / Toshiba PX04SRB384 3.84TB 2.5" SFF 12Gbps MLC Read Intensive SAS Solid State Drive - Brand New
Highlights
- Offers up to 3.84 TB storage capacity
- Equipped with Serial Attached SCSI (SAS) interface which delivers high data transfer rate
- Solid State design offers ruggedness and fast data access
Benefits of SSD over spin drives:
- More Durable: Feature a non-mechanical design of NAND flash mounted on circuit boards, and are more shock resistant.
- Faster: Faster data access, boot ups, file transfers, and an overall quicker computing experience than hard drives.
- Quieter: Run at near silent operation unlike loud, whirring hard disc drives.
- Lighter: Flash-based SSDs weigh considerably less.
- Cooler: SSDs require little power to operate, resulting in less heat output by your system.
- More Efficient: Consume less power at peak load.
Overview
Increase the storage capacity of your Dell™ System with 3.84 TB Solid State Drive from Dell. It boasts a storage capacity of up to 3.84 TB, enabling users to store large amounts of data. This drive delivers enhanced data transfer speed of up to 12 Gbps.
Manufacturer Part# :PX04SRB384
Dell Part# :519NF 0519NF MW5KG 0MW5KG
This drive is compatible with:
Equallogic PS6110, PS4110, PS6100XS, PS6100XV, PS6100X, PS6100S, PS6110XS, PS6110XV, PS6110S, PS6110X, PS4100E, PS-M4110
Compatibility
This drive is compatible with:
- Equallogic PS6110
- Equallogic PS4110,
- Equallogic PS6100XS
- Equallogic PS6100XV
- Equallogic PS6100S
- Equallogic PS6100X
- Equallogic PS6110XS
- Equallogic PS6110XV
- Equallogic PS6110S
- Equallogic PS6110X
- Equallogic PS4100E
- Equallogic PS-M4110
Specifications
| Enterprise Read Intensive SSD | |
|---|---|
| Model Number | PX04SRB384 |
| Basic Specifications | |
| Interface | SAS-3.0 |
| Interface Speed | 12.0 Gbit/s , 6.0 Gbit/s , 3.0 Gbit/s , 1.5 Gbit/s |
| Memory Type | MLC |
| Formatted Capacity | 3.84TB / 3,840GB |
| Sustained 64KiB Sequential Read | 1,500 MiB/s |
| Sustained 64KiB Sequential Write | 750 MiB/s |
| Sustained 4KiB Random Read | 270,000 IOPS |
| Sustained 4KiB Random Write | 22,000 IOPS |
| Reliability | |
| MTTF | 2,000,000 hours |
| DWPD | 1 |
| Power Requirements | |
| Supply Voltage | 5 V ±7 % , 12 V ±7 % |
| Power Consumption (Operating) | 3.2W Typ. |
| Dimensions | |
| Height | 15.0 mm +0 , -0.5 mm |
| Width | 69.85 ±0.25 mm |
| Length | 100.45 mm Max. |
| Weight | 150 g Max. |
| Enviromental | |
| Temperature (Operating) | 0 to 55 °C |
| Relative Humidity ( Operating ) | 5 to 95 % R.H. |
| Vibration (Operating) | 21.27 m/s {2.17 Grms} (100 to 800 Hz) |
| Shock (Operating) | 9.8 km/s {1,000 G} (0.5 msec) |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 519NF 0519NF MW5KG 0MW5KG
Weight: 1.5 lb
Warranty: 1 Year DiscTech
Condition
Brand New
Warranty
1 Year DiscTech Warranty
