SAMSUNG Part #/MPN: MZILS480HEGR-000D4
DiscTech Item #: SAM-MZILS480HEGR-000D4-BN-OE-DEQ
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- In Stock:1Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Enterprise Grade
Capacity: 480GB
Speed: Solid State Memory
Interface Types: SAS Serial Attached SCSI
Form Factor: 2.5inx15mm SFF Server Drive
Sector Size: 512 / 512e
Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps
SSD Type: TLC
SSD Endurance DWPD: Enterprise Read Intensive
Compatible Systems: Dell 14th Gen. R640/R740, Dell 13th Gen. R730/T630, Dell 12th Gen M420 M620 M640 M820 Blade, Dell 12th Gen. R720/T620
Dell Equallogic JKYYN / Samsung PM1633a Series MZILS480HEGR-000D4 / MZ-ILS480B 480GB 12Gbps 2.5in SFF Enterprise SAS SSD - Brand New OEM
- Ultra-High Capacity SAS SSD
- High Speed with Low Latency
- Reliable Storage, 24/7 Operation
- Top Solution for Diverse Applications
- Best Solution for Heavy Demands
Alt MPN: JKYYN MZILS480HEGR-000D4 MZ-ILS480B
PM1633a 2.5” SAS SSD Samsung PM1633a solid-state drive offers up to 1,000 times the performance of 15K RPM hard disk drives at a comparable cost per gigabyte.
Samsung PM1633a SAS SSD delivers:
Consistently High Performance – Up to 1,000 times the performance of the fastest 15K RPM hard drives, the Samsung PM1633a SAS SSD provides enterprise IT administrators performance to spare. An optimized Samsung native SAS 3.0 controller supplies the drive with 12 Gb/s of bandwidth and provides enterprises the performance margin to prevent costly and disruptive application support tickets. Exceptional Value – The same low cost per gigabyte as slower SAS HDDs. By utilizing Samsung state-of-the-art 3D V-NAND flash memory, cost effective TLC flash memory can address high-end enterprise applications, outperforming older planar MLC flash memory, and providing solid state performance and reliability at hard drive cost. With no moving parts, the PM1633a SAS SSD delivers over 10 times the reliability of spinning disks, reducing the administrative cost overhead associated with drive replacement. Breakthrough Storage Density – Capacities up to 16TB in a 2.5” small form factor (SFF) drive. With 60% higher capacity per drive, and a smaller 2.5” form factor, up to 384TB can be stored in a 2U server. This breakthrough in storage density more than triples the density available with high capacity HDDs, using an industry standard form factor, and without sacrificing enterprise reliability, availability, and serviceability (RAS). DP/N: 8Y64H 08Y64H
| Model | PM1633a |
| F/F | 2.5 inch |
| Seq. Read | 1250 MB/s |
| Ran. Read | 200 KIOPS |
| DWPD | 1 DWPD |
| Interface | SAS 12.0 Gbps |
| Capacity | 480 GB |
| Seq. Write | 600 MB/s |
| Ran. Write | 20 KIOPS |
Alternate MPNs: JKYYN 0JKYYN MZ-ILS480B
Weight: 1 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
