Dell GD3N0 / KIOXIA KPM6XVUG1T60 1.6TB 2.5inch 12Gbps Mixed Use TLC SAS SSD 3-DWPD PM6-V Series SAS-3 ME5
| Capacity: | 1.6TB |
| Speed: | Solid State |
| Interface Types: | SAS |
| Form Factor: | 2.5" SFF Server Drive |
| SSD Endurance DWPD: | Enterprise Mixed Use / MU |
| Electrical Interface: | SAS-3 12Gbps |
Description
Dell GD3N0 / KIOXIA KPM6XVUG1T60 1.6TB 2.5inch 12Gbps Mixed Use TLC SAS SSD 3-DWPD PM6-V Series SAS-3- Brand New
PM6-V Series - Enterprise Mixed Use SAS SSD
KIOXIA PM6-V Series 12G SAS Enterprise SSD is optimized for mixed use applications, including relational database, streaming media, data warehousing and web services. The series is designed to deliver balanced levels of performance, reliability, capacity and endurance for mixed use and read intensive environments.
Key Features:
- 12.0 Gbit/s SAS interface with single/dual port
- Capacities from 1.6TB to 12.8TB
- Up to 720K random read IOPS (4 KiB) in dual-port mode
- 2.5 inch form factor, 15 mm thickness
- 3 DWPD with 100 % Random Write Workload
- Power loss protection and end-to-end data protection, including T10 DIF Pin-3 power disable support
- Security options: SIE, SED, FIPS SED
Key Applications
- Web Servers
- Data Warehousing
- Streaming Media
DPN: GD3N0 , 0GD3N0
Compatibility:
This drive is designed to work in the Dell ME5 series arrays. This includes the ME5012, ME5024, ME5084, ME412, ME424, ME484. It will also work in the Dell PowerEdge and PowerVault systems.
Specifications
| Enterprise Read Intensive SSD | |
|---|---|
| Basic Specifications | |
| Reliability | |
| Power Requirements | |
| Dimensions | |
| Enviromental | |
| Model Number | KPM6XVUG1T60 |
| Interface | SAS-3.0 |
| Interface Speed | 22.5 Gbit/s , 12.0 Gbit/s , 6.0 Gbit/s , 3.0 Gbit/s , 1.5 Gbit/s |
| Memory Type | BiCS FLASH TLC |
| Formatted Capacity | 1.6TB |
| Sustained 1284KiB Sequential Read | 4,150 MiB/s |
| Sustained 128KiB Sequential Write | 2,700 MiB/s |
| Sustained 4KiB Random Read | 595,000 IOPS |
| Sustained 4KiB Random Write (in dual port mode) | 265,000 IOPS |
| MTTF | 2,500,000 hours |
| DWPD | 3 |
| Supply Voltage | 5 V ±7 % , 12 V ±7 % |
| Power Consumption (Operating) | 5.0W Typ. |
| Height | 15.0 mm +0 , -0.5 mm |
| Width | 69.85 ±0.25 mm |
| Length | 100.45 mm Max. |
| Weight | 130 g Max. |
| Temperature (Operating) | 0 to 60 °C |
| Relative Humidity ( Operating ) | 5 to 95 % R.H. |
| Vibration (Operating) | 21.27 m/s {2.17 Grms} (100 to 800 Hz) |
| Shock (Operating) | 9.8 km/s {1,000 G} (0.5 msec) |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: GD3N0 0GD3N0
Weight: 0.7 lb
Warranty: 1 Year DiscTech
Condition
Brand New
Warranty
1 Year DiscTech Warranty
