Toshiba Part #/MPN: MG03SCA100
DiscTech Item #: TOS-MG03SCA100-RF-OE-DEL
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Special Order - Ships in 5-10 business daysSpecial Order - Ships in 5-10 business days
This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
Enterprise Grade
Capacity: 1TB
Speed: 7,200RPM
Interface Types: SAS Serial Attached SCSI
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 155
Average Seek Time: 8.5 / 9.5
Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps
On-Board Cache: 64MB
Dell GPP3G / Toshiba MG03SCA100 1TB / 1000GB 7.2K 6.0Gbps SAS Hard Drive - Refurbished OEM
Dell GPP3G / Toshiba MG03SCA100 1TB / 1000GB 7,200 RPM 6Gbps SAS Hard Drive - Refurbished OEM
Alt MPNs: 0GPP3G, GPP3G, HDEPC03DLA51
Overview
The new reliable nearline model features a top storage capacity of up to 4 TB in a 3.5-inch form factor and leading-edge 6Gb/sec SAS interface. Intended for 24 x 7 operation, the MG03SCAxxx also includes features that are critical to business operations such as enhanced Error Correction Code (ECC), Anti Rotational Vibration (RV) technology for multi-drive systems, and enhanced power condition state technology.
The MG03SCAxxx provides a flexible and cost effective storage solution for enterprise applications including entry-level servers, storage arrays, RAID systems as well as private cloud storage.
This series is also available with enhanced secure cryptographic erase function [Models MG03SCP100, MG03SCP200, MG03SCP300 and MG03SCP400], which can invalidate all data saved on the disk in an instant.
Compatibility:
This drive is compatible with any of our SAS drive trays and any of our SAS controllers.
Drive specification | MG03SCA100 |
Formatted Gbytes (512 bytes/sector) | 1000 |
Bytes per sector | 512 |
Spindle speed (RPM) | 7,200 |
I/O data transfer rate (MBps) | 600 |
Cache buffer | 64MB |
Interface Type | 6.0Gbps SAS 2.0 |
Seek time (read / write) ms | 9.5 |
ROHS | Yes |
Dimensions (HxLxW) mm | 26.1 / 147 / 101.6 |
Weight | 0.8 kg |
Operating Shock (Read) | 70G, 2ms |
Non-operating Shock | 300G, 2ms |
MTBF | 1,200,000 hrs |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 0GPP3G GPP3G HDEPC03DLA51
Weight: 1.8 lb
