Dell J770N / Seagate Constellation ST9500530NS 500GB 7.2K SATA Enterprise Hard Drive
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 500GB |
| Speed: | 7.2K RPM |
| Interface Types: | SATA |
| Form Factor: | 2.5" SFF Server Drive |
| Electrical Interface: | SATA 300 - 3Gbps |
| RAM: | 32MB |
Description
Dell J770N / Seagate Constellation ST9500530NS 500GB 7.2K SATA Enterprise Hard Drive - Refurbished OEM
The Constellation 7200 hard drive enables manageable nearline storage solutions in 2.5" chassis — either direct attach or in a tiered storage environment — at the lowest power usage without compromising performance or reliability. Constellation 500GB SATA drives deliver cost-effective, eco-friendly nearline storage.
Key Features and Benefits- Lowest operating power & enhanced power options with PowerChoice™ for even greater power savings during slow or idle periods
- First 2.5", 15mm business critical drive on the market designed for enterprise reliability, vibration performance and high data integrity. Fits in more server & storage slots!
- Fastest Tier 2/Nearline HDD on the market (SAS @ 6Gb/s speed). At a system level (with more drives) the performance will be >2x as compared to 3.5" HDD.
- The highest capacity 2.5" enterprise drive with 500GB with both SAS and SATA interfaces. (160GB SATA also available for boot/entry server applications)
- 6Gbps SAS 2.0 allows for easier integration, enhanced features and outstanding performance
- Government-grade self-encrypting drive (SED) on SAS models
- Best performing nearline drive with Best-in-class Rotational Vibration
Alt PNs: 0J770N J770N
Compatibility
This drive is compatible with any of our SATA drive trays and any of our SATA controllers.
Specifications
Drive specification | ST9500530NS |
Formatted Gbytes (512 bytes/sector) | 500 |
Bytes per sector | 512 |
Spindle speed (RPM) | 7,200 |
I/O data transfer rate (MBps) | 300 |
Cache buffer | 32 |
Interface Type | Serial ATA-300 |
Average latency | 4.16 ms |
Seek time (read / write) ms | 8.5 / 9.5 |
Track-to-track seek (read / write) ms | 0.8 / 1.0 |
Dimensions (HxLxW) mm | 14.8 / 100.5 / 70 |
Weight | 0.196 kg |
Operating Shock (Read) | 70G, 2ms |
Non-operating Shock | 400G, 2ms |
Temperature - Operating | 5C -55C |
Temperature - Non-operating | -40C - 70C |
Current Requirements 12VDC (Read/Write, Idle) | 3.5w / 2.6w |
Click here to view the manufacturer's item description/brochure
Alternate MPNs: 0J770N J770N
Weight: 0.5 lb
Warranty: 1 Year DiscTech
Condition
Refurbished
Warranty
1 Year DiscTech Warranty
