Dell V9H6C / 1W10017 / HUS722T2TALA600 2TB 3.5" 6Gbps 7.2K RPM 512n SATA Hard Drive

Dell Part #/MPN: V9H6C

DiscTech Item #: DEL-V9H6C-NP-OE


$159.00
  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

$159.00

Enterprise Grade

Capacity: 2TB

Speed: 7,200RPM

Interface Types: SATA

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 191/200

Average Seek Time: 4.2

Electrical Interface: SATA 600 - 6.0Gbps

On-Board Cache: 128MB

Compatible Systems: Dell 14th Gen. R640/R740, Dell 13th Gen. R730/T630, Dell 12th Gen. R720/T620, Dell 11th Gen. R710/T610

Dell V9H6C / 1W10017 / HUS722T2TALA600 2TB 3.5" 6Gbps 7.2K RPM 512n SATA Hard Drive - New Pull

Dell V9H6C / 1W10017 / HUS722T2TALA600 2TB 3.5" 6Gbps 7.2K RPM 512n SATA Hard Drive - New Pull

Dell DP/N: 0V9H6C 1W0017

HGST Ultrastar® 7K2 Now a Western Digital Company

Value to the Data Center with Performance-optimized Capacity for High-intensity Applications
Data centers that need fast access to data in Tier 2 environments need look no further. The HGST Ultrastar 7K2 delivers fast data access in capacityoptimized, enterprise-class storage systems. Enhanced RAFF™ technology in the 7K2 includes sophisticated electronics to monitor the drive and correct both linear and rotational vibration disturbances in real time—especially helpful in multi-drive arrays and rack-mounted systems maintaining high read/ write performance. Designed to handle workloads up to 550TB per year, the Ultrastar 7K2 delivers up to 2TB of affordable storage capacity for highintensity applications in enterprise-class environments.

Maximize Your Data Center Application Investment with Proven Storage Technology
Data centers face growing pressures to store more with flat-to-shrinking budgets. Keeping systems operational for as long as possible to maximize investments can be an effective part of the strategy, but supporting those legacy applications becomes even more challenging as drive technologies move to next generation formats and interfaces. The 7K2 has a SATA 6Gb/s interface and native 512-byte (512n) sector size to provide consistent, high performance and compatibility with legacy data center applications. Dualstage actuator technology provides a head positioning system that improves positional accuracy over the data tracks, enabling data to be written to and read from the drive more reliably. Trust HGST to deliver storage options that allow data centers to get the most from their hardware investment.

Designed with Data Center Requirements in Mind
Multi-axis shock sensor technology automatically detects the smallest shock events and compensates to protect stored data. RAID-specific, time-limited error recovery reduces drive fallout caused by extended hard drive errorrecovery processes. Ramp load/unload technology keeps the recording heads away from the disk media during idle time and power down, ensuring significantly less wear to the recording heads and media as well as better drive protection in transit. Through the use of dynamic fly height technology, each read-write head’s fly height is adjusted in real time for optimum reliability and performance. With a 2M hour MTBF rating and a 5-year warranty, rely on Ultrastar 7K2 to deliver capacity, performance and reliability for more value to your data center.

Highlights

  • Up to 2TB capacity1 in a standard 3.5-inch form factor
  • Enhanced RAFF™ anti-vibration technology for robust performance in multi-drive environments
  • Reliable, field-proven design
  • SATA 6Gb/s with 512-byte (512n) supports legacy enterprise applications
  • 2M hours MTBF2 rating



Applications/Environments

  • RAID arrays
  • Massive scale-out (MSO) data centers
  • Data warehousing & mining
  • Cloud storage
  • Enterprise NAS
  • Disk-to-disk backup & archiving
  • Legacy mainstream enterprise capacity applications that require 512n block size




Compatibility:

This drive is compatible with any server that accepts 3.5inx1.0in SATA Drive.

Hitachi Ultrastar 7K2
Model Number1W10017 / V9H6C
Alt Model NumberHUS722T2TALA600
Configuration
InterfaceSATA 6Gb/s
Capacity2TB / 2000GB
Sector size (variable, bytes/sector)512 native (512n)
Max. areal density (Gbits/sq. in)638
Performance
Data buffer (MB)128
Rotational speed (RPM)7200
Latency average (ms)4.2
Interface transfer rate (MB/s, max)600
Sustained transfer rate (MB/s, typical)191/200
Seek time (read/write, ms, typical range)7.7
Reliability
Error rate (non-recoverable, bits read)1 in 10^16
Load/Unload cycles (40°C)600,000
MTBF (M hours)2.0
Annualized Failure Rate (AFR)0.44%
Availability (hrs/day x days/wk)24x7
Acoustics
Idle (Bels)2.5
Power
Requirements+5V, +12V
Operating, (W, typical)8.1
Idle (W)5.9
Power consumption efficiency at idle
(Watts/TB)
(Watts/GB)

2.95
0.00295
Physical
z-height (mm)26.1
Dimensions (width x depth, mm)101.6 (+/-0.25) x 147 (max)
Weight (g, max)640 (+/-10%)
Environmental (operating)
Ambient temperature 5o to 55° C
Shock (half-sine wave 2ms, read operation)65 (2 ms)
Vibration, random, no errors (G RMS 5 to 500 Hz)1.08 (XYZ)
Environmental (non-operating)
Ambient temperature -40 to 70° C
Shock (half-sine wave 2ms, read operation)300 (2ms)
Vibration, random (G RMS 5 to 500 Hz)3.8 (XYZ)

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: 1W10017 0V9H6C HUS722T2TALA600

Weight: 1.8 lb

Warranty: 1 Year DiscTech

New Pull

Condition Levels Explained

The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
