Dell VRTN9 1.92TB SAS 24Gbps Read Intensive SSD PowerVault ME4 ME5 KIOXIA Toshiba KPM6XRUG1T92

Toshiba KPM6XRUG1T92 VRTN9 0VRTN9 Dell 1.92TB 24Gbps SAS SSD ME4 / ME5 Image 1 imageToshiba KPM6XRUG1T92 VRTN9 0VRTN9 Dell 1.92TB 24Gbps SAS SSD ME4 / ME5 Image 2 imageToshiba KPM6XRUG1T92 VRTN9 0VRTN9 Dell 1.92TB 24Gbps SAS SSD ME4 / ME5 Image 3 image
  • Brand New
    Condition Levels Explained

    The product is brand new.

  • In Stock:2
    Need more?
    Stock Levels

    This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.

  • 1 Year DiscTechWarranty
    Product Warranties Explained

    The product has a DiscTech warranty for the time period specified. View our limited warranty

$1,049.00

Capacity:1.92TB
Speed:Solid State
Interface Types:SAS
Form Factor:2.5" SFF Server Drive
SSD Endurance DWPD:Enterprise Read Intensive / RI
Electrical Interface:SAS-4 24Gbps
Click to see more 1.92TB SAS Solid State Drives

Description

Dell VRTN9 / KIOXIA Toshiba KPM6XRUG1T92 1.92TB 2.5" 24Gbps Read Intensive SAS SSD ME4 ME5 - Brand New OEM

Dell VRTN9 / KIOXIA Toshiba KPM6XRUG1T92 1.92TB 2.5" 24Gbps Read Intensive SAS SSD - Brand New OEM

KIOXIA PM6-R Series

KIOXIA PM6-R Series 24G SAS Enterprise SSD is optimized for read intensive applications, including web services, data warehousing, streaming media and video on demand. The series provides high levels of performance, reliability and endurance, and is designed to minimize total cost of ownership.

Featuring KIOXIA Corporation’s 96-layer BiCS FLASHTM 3D flash memory, this 6th generation enterprise SAS SSD PM6-R Series offers 1 DWPD (Drive Writes Per Day) with capacities up to 30.72 TB.

  • 24G SAS interface with single/dual-port support
  • Capacities from 1.92 TB to 30.72 TB
  • Up to 720K random read IOPS (4 KiB) in dual-port mode
  • 2.5-inch form factor, 15 mm thickness
  • 1 DWPD with 100 % Random Write Workload
  • Power Loss Protection and End-to-End Data Protection, including T10 DIF
  • Security options: SIE, SED, FIPS SED
  • 5-year limited warranty

Compatibility

This drive is designed to work in the Dell ME4 and ME5 series arrays. This includes the ME4012, ME4024, ME4084, ME5012, ME5024, ME5084, ME412, ME424, ME484. It will also work in the Dell PowerEdge and PowerVault systems.

Specifications

Enterprise Read Intensive SSD
Basic Specifications
Reliability
Power Requirements
Dimensions
Enviromental
Model NumberKPM6XRUG1T92
InterfaceSAS-4.0
Interface Speed22.5 Gbit/s,12.0 Gbit/s ,6.0 Gbit/s ,3.0 Gbit/s ,1.5 Gbit/s
Memory TypeBiCS FLASH TLC
Formatted Capacity1.92TB
Sustained 128KiB Sequential Read4,150 MiB/s
Sustained 128KiB Sequential Write2,700 MiB/s
Sustained 4KiB Random Read595,000 IOPS
Sustained 4KiB Random Write125,000 IOPS
MTTF2,500,000 hours
DWPD1
Supply Voltage12 V ± 10 %, 5 V +10 % / -7 %
Power Consumption (Operating)5W Typ.
Height15.0 mm +0 , -0.5 mm
Width69.85 ±0.25 mm
Length100.45 mm Max.
Weight130 g Max.
Temperature (Operating)0 to 70 °C
Relative Humidity ( Operating )5 to 95 % R.H.
Vibration (Operating)21.27 m/s {2.17 Grms} (5 to 800 Hz)
Shock (Operating)9.8 km/s {1,000 G} (0.5 msec)
Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: VRTN9 0VRTN9

Weight: 0.7 lb

Warranty: 1 Year DiscTech

Condition

Brand New

Warranty

1 Year DiscTech Warranty
