Seagate Part #/MPN: ST2000NM0018
DiscTech Item #: SGT-ST2000NM0018-NP-OE-DEL
- New PullCondition Levels Explained
The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Enterprise Grade
Capacity: 2TB
Speed: 7,200RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 185
Average Seek Time: 4.16
Electrical Interface: SATA 600 - 6.0Gbps
On-Board Cache: 128MB
Dell W8FW5 Seagate Enterprise Capacity ST2000NM0018 2TB / 2000GB 7.2K 6.0Gbps SATA ISE 512n Hard Drive - New Pull OEM
The Seagate® Enterprise Capacity 3.5" LFF HDD delivers the reliability and capacity that data centers need.
These drives provide the following key features:
• 7200 RPM spindle speed.
• Compliant with RoHS requirements in China and Europe.
• Full-track multiple-sector transfer capability without local processor intervention.
• High instantaneous (burst) data-transfer rates (up to 600MB per second).
• Native Command Queuing with command ordering to increase performance in demanding applications.
• Perpendicular recording technology provides the drives with increased areal density.
• PowerChoice™ for selectable power savings
• SeaTools™ diagnostic software performs a drive self-test that eliminates unnecessary drive returns.
• State-of-the-art cache and on-the-fly error-correction algorithms.
• Support for S.M.A.R.T. drive monitoring and reporting.
• Supports latching SATA cables and connectors.
• Tarnish-resistant components to help protect drive from environmental elements, increasing field reliability
• Worldwide Name (WWN) capability uniquely identifies the drive.
PN: 2F3130-136
DPN: W8FW5 / 0W8FW5
Compatibility:
This Seagate Enterprise hard disk is compatible by any system that supports 3.5" SATA hard disks.
| Specifications | |
| Interface | SATA III 6Gb/s |
| Capacity | 2TB |
| Model Number | ST2000NM0018 |
| Features | |
| Cache Buffer (MB) | 128 |
| Reliability/Data Integrity | |
| Mean Time Between Failures (MTBF, hours) | 2 million |
| Bytes per Sector | 512 Native |
| Performance | |
| Spindle Speed (RPM) | 7200 |
| Max. Sustained Transfer Rate OD (MB/s) | 185 |
| Average Latency (ms) | 4.16 |
| Interace Ports | Single |
| Rotation Vibration @ 1500 Hz (rad/s²) | 12.5 |
| Power Consumption | |
| Idle Power (W) | 4.64 |
| Typical Operating, Random Read (W) | 8.3 |
| Power Supply Requirements | +12V and +5V |
| Environmental | |
| Temperature, Operating (°C) | 5 to 60 |
| Physical | |
| Height (in/mm, max)5 | 1.028/26.1 |
| Width (in/mm, max)5 | 4.010/101.85 |
| Depth (in/mm, max)5 | 5.878/147.0 |
| Weight (lb/g) | 1.213/550 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 2F3130-136 W8FW5 0W8FW5
Weight: 1.8 lb
Warranty: 1 Year DiscTech
