Drobo 5D3 Platinum Edition DRDR6A21-P Diskless 5-Bay Direct Attached Storage Array

DROBO Part #/MPN: DRDR6A21-P

DiscTech Item #: DRO-DRDR6A21-P-BN-5Y


$1,209.00
  • Low Stock:Call for ETA
$1,209.00

Interface Types: SATA, SATA 1.8in Mini-SATA / MSATA, USB 3.0 3.1 3.2, USB Type C, Thunderbolt

Form Factor: 3.5" LFF Hard Drive

Encryption/SED Supported

Electrical Interface: Thunderbolt 3 - 40Gbps

Bays/Ports/Slots: 5

Wattage/VA: 120W

Voltage: 110-240V Multi

Drobo 5D3 Platinum Edition DRDR6A21-P Diskless 5-Bay Thunderbolt3 / USB 3.0, Type C DAS Storage Array w/ 128G mSATA, Drobo Care and DriveSavers - Brand New

Drobo 5D3 Platinum Edition DRDR6A21-P Diskless 5-Bay Thunderbolt3 / USB 3.0, Type C DAS / Direct Attached Storage Array with 128G mSATA / Mini-SATA / Mini Serial ATA, Drobo Care and DriveSavers - Brand New

Platinum Edition Includes:

  • 5 Years of premium DroboCare Warranty Service
  • 5 Year Drive Recovery Service Plan (for a one-time service) provided by DriveSavers
  • 128GB mSATA SSD Card for Accelerator Bay

Drobo 5D3 Platinum Edition Overview
The 5D3 5-Bay Thunderbolt 3 Enclosure (Platinum Edition) from Drobo improves upon the original 5D3 by pairing it with a 128GB mSATA SSD, five years of DroboCare warranty services, and a five-year drive recovery service plan from DriveSavers. The 128GB mSATA SSD is installed into the unit's Accelerator Bay and boosts system performance by placing data that is read or written into SSD storage. When the data is active, it is stored in the SSD and will be moved back to the hard drive tier as its use decreases. Upon product registration, the extended five-year DroboCare warranty provides hardware replacement, technical support, and migration assistance. Lastly, in the event of drive failures or data loss, the five-year drive recovery service plan from DriveSavers is good for a one-time use.

Drobo has designed the 5D3 for media professionals, content creators, and small businesses running Apple Final Cut Pro, Adobe Lightroom, and other I/O intensive applications, or even those who just need to back up terabytes of data. It is equipped with five 3.5" SATA drive bays that support 3.5/2.5" SATA III 6 Gb/s and SATA II 3 Gb/s hard drives and SSDs. The 5D3 distinguishes itself from the original Drobo 5D and 5Dt through the inclusion of Thunderbolt 3 technology, which is accessed through two integrated Thunderbolt 3 ports. While one of the Thunderbolt 3 ports is used to connect the 5D3 to your compatible system, the second one is used to daisy-chain up to six Thunderbolt devices together, including one 5K display or two 4K displays. The Thunderbolt 3 ports also provide 15W of charging power for Thunderbolt 3 laptops, and there is also one USB 3.0 Type-C port, which transfers data at speeds up to 5 Gb/s. Please be aware that the 5D3's Thunderbolt 3 ports are only compatible with Mac, while the USB 3.0 Type-C port can be used with both Windows and Mac. Mac support includes APFS/macOS High Sierra.

To facilitate data protection, Drobo's BeyondRAID technology enables single or dual-drive redundancy. If there are any empty drive bays, BeyondRAID allows additional drives to be inserted into the array, where they would be automatically configured. If all drive bays are occupied, simply replace the smallest capacity drive with a larger one and BeyondRAID will handle the rest. BeyondRAID is also what allows drives of varying capacities to work in the same unit, which helps enable future expansion as larger drives become available.

Additional data protection is provided by the included rechargeable battery, which helps protect data stored in the 5D3's cache. If there were to be a sudden power loss, the battery allows the Drobo to stay powered long enough for the cached data to be written to non-volatile storage. Cooling is provided by a 120mm variable-speed fan and once installed, the hard drives can be configured to spin down when they're not in use, helping to further reduce noise and energy. Also, the LEDs can be dimmed to reduce light pollution when working in sensitive environments. The Drobo 5D3 also includes a 3.3' Thunderbolt 3 cable and a 6.0' power cord with a power supply that operates using 100-240 VAC at 50-60 Hz.

Data Protection and Expandability
Built on award-winning BeyondRAID technology with single- or dual-drive redundancy, the Drobo 5D3 protects your data without any user interaction, even in the event of multiple drive failures.

Drives can be added or hot-swapped and updated in real time for storage expansion with zero downtime. If you're running low on space, the lights on the front tell you what to do. Just add a drive in an empty bay or remove a smaller drive and replace it with a larger one. Consult the online capacity calculator to determine how the choice of drive size, number of drives, and protection levels affect available capacity.

The Power of Thunderbolt 3 and Flexibility of USB Type-C
Thunderbolt 3 technology provides performance that's twice as fast as the previous generation. This optimizes your performance when transferring large volumes of data.

The Drobo 5D3 is equipped with dual Thunderbolt 3 ports for daisy chaining on Mac only. Connect up to six Thunderbolt devices and/or a non-Thunderbolt monitor at the end of the chain. The 5D3 supports one 5K monitor, or two 4K monitors, and 15W of power for device charging. By having 5D3 arrays in a chain, you can have up to 300TB of usable capacity and achieve throughput by enabling the bi-directional 40 Gb/s performance of Thunderbolt 3. It is compatible with systems running supported versions of macOS X, including APFS/macOS High Sierra, as well as Windows, with Windows compatibility only available using the USB 3.0 Type-C port.

Capacity and Performance
The Drobo 5D3 includes a built-in Accelerator Bay, with an 128GB mSATA SSD. Their patented Accelerator Cache technology keeps a copy of your most frequently accessed data to deliver fast speeds. The accelerator cache can dramatically speed up loading large photo libraries and other I/O intensive operations, smoothing out workflows allowing you to optimize productivity for applications such as Apple Final Cut Pro X and Adobe Lightroom.

Data Recovery
Drobo has partnered with DriveSavers Data Recovery for added peace of mind in case of data loss from your hard drives. This 5-year coverage plan is good for one use and can potentially save you thousands of dollars in the case of a failed disk pack.

Enhanced Time Machine Support
Drobo is compatible with Apple's Time Machine, which will consume the capacity of an external storage system. By utilizing the Drobo Dashboard, you can simply allocate capacity limits for backups and data storage.

Power Protecting Your Critical Data
Drobo doesn't just protect you from a drive failure, but also from potential data loss after a power outage. Often found only in arrays that cost tens of thousands of dollars, the Drobo 5D3 includes a battery that protects all data in the memory, or cache, that is, data on its way to the drives.

During a sudden power loss, the internal battery keeps the Drobo alive long enough for the data to be written to non-volatile storage. The battery recharges itself and lasts for the life of the product.

Drobo Dashboard
Drobo Dashboard is the single tool used to centrally manage all of your Drobo devices. Drobo Dashboard displays status as if all of your Drobos were right in front of you with the same status lights and capacity gauge that are on the front panel. All administration tasks are a single click away.

Designed for You
Drobo devices have always been space efficient and the Drobo 5D3 is no exception. It is designed to provide high capacity, without taking up a lot of your valuable desk space. It is compact because of Drobo's carrier-less drive bay design, allowing drives to be installed very close to each other. Users can also dim the lights and configure drives to spin down when not in use. Included is a Thunderbolt 3 cable.

In the Box

  • Drobo 5D3
  • 3.3 ft. (1 m) Thunderbolt 3 cable (20Gb/s)
  • 6 ft. (1.8 m) power cord with power supply
  • 128GB mSATA SSD card
  • DroboCare Card
  • DriveSavers Card
  • Quick Start Card

Drobo 5D3 Platinum Edition
MANUFACTURER PART NUMBERDRDR6A21-P
GENERAL
Capacity:
  • Diskless
Connectivity:
  • 2 x Thunderbolt 3 ports; second port for daisy-chaining Thunderbolt devices, including one 5K or two 4K displays (Mac OS X only)
  • 1 x USB 3.0 Type-C port
Drives and Expansion:
  • Up to five 3.5" SATA II/III hard disk drives or solid-state drives
  • One mSATA solid-state drive in the Drobo Accelerator Bay for increased performance (sold separately)
  • Drives of any manufacturer, capacity, spindle speed, and/or cache can be used. No carrier or tools required
  • Expandable by adding drives or hot-swapping drives with larger ones
BeyondRAID Features:
  • Thin Provisioning
  • Instant Expansion
  • Mixed Drive Size Utilization
  • Automatic Protection Levels
  • Single or Dual Disk Redundancy
  • Virtual Hot Spare
  • Data Aware
  • Drive Re-ordering
Management:
  • Drive bay indicator lights, capacity gauge, status lights
  • Drobo Dashboard version 3.1.0 or later
Operating System Support:
  • Apple macOS X 10.10 and higher
  • Microsoft Windows 10, 8, and 7
File Systems Supported:
  • Mac OS X: HFS+
  • Windows: NTFS
Hardware Features:
  • Carrier-less drive bays
  • Power fail protection with internal battery
  • Metal chassis and cover
  • Kensington Lock Port for security (lock not included)
Additional Software Features:
  • Hot Data Caching
  • Drive Spin Down
  • Dim Lights
  • OS X Time Machine Support
  • Windows Backup Support
Power and Cooling:
  • External Power Supply
  • AC Input: 100 to 240 VAC ~ 2 A, 50 to 60 Hz
  • DC Output: 12 V, 10 A, 120 W max
    • Fixed, 120 mm variable speed cooling fan
    • 15 W of power to slow charge a Thunderbolt 3 laptop
Form Factor:
  • Desktop
Dimensions (L x W x H):
  • 5.9 x 7.3 x 10.3"
  • 150 x 185 x 262 mm
Box Dimensions (L x W x H):
  • 19.7 x 14.3 x 13.7"
Weight:
  • Without Drives
    • 8.5 lb
    • 3.9 kg
Package Weight:
  • 22.85 lbs


Pricing and product availability subject to change without notice.


Click here to view the manufacturer's item description/brochure

Weight: 10 lb

Warranty: 5 Year Manufacturer

Brand New

5 Year Manufacturer Warranty
