EMC 118000130-01 800GB 12Gbps MLC SAS SSD

EMC Part #/MPN: 118000130-01

DiscTech Item #: EMC-118000130-01-BN-OE


Enterprise Grade

Capacity: 800GB

Speed: Solid State Memory

Interface Types: SAS Serial Attached SCSI

Form Factor: 2.5inx15mm SFF Server Drive

Sector Size: 512 / 512e

Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps


SSD Endurance DWPD: Enterprise Mixed Use

EMC 118000130-01 0B33600 HUSMM1680ASS200 Crypto Enabled 800GB 12Gbps 2.5" SFF Enterprise MLC SAS SSD - Brand New

EMC 118000130-01 0B33600 HUSMM1680ASS200 Crypto Enabled 800GB 12Gbps 2.5" SFF Enterprise MLC SAS SSD - Brand New

EMC / HGST Enterprise Storage

EMC leverages decades of proven enterprise storage expertise in Serial Attached SCSI (SAS) design, reliability, firmware, customer qualification and system integration to the Ultrastar® SSD1600MM solid-state drive (SSD) family. The synergistic relationship between HGST’s throughput-enhancing SSDs and traditional HDDs provides cost effective, end-to-end enterprise-class storage solutions, delivering reliability, compatibility, capacity, cost and system performance. This combination makes HGST a leading SSD/HDD provider with the experience and technology needed to meet escalating reliability, endurance and performance in the most demanding enterprise environments.

Maximum Performance,

Reliability and Endurance The Ultrastar SSD1600MM delivers high sequential throughput, up to 1100MB/s read and 765MB/s write (12Gb/s SAS). It also delivers up to 130,000 read and 100,000 write IOPS, reaching speeds >100 times faster than HDDs and double the speed of current 6Gb/s SSDs, allowing rapid access to “hot” enterprise data for improved productivity and operational efficiency. The Ultrastar SSD1600MM family offers significant value in terms of IOPS per Watt, while reducing total cost of ownership (TCO) through low power consumption, efficient cooling and reduced space requirements.

Alt Pt#" 0B33600 / HUSMM1680ASS200


This drive is compatible with EMC servers and storage arrays that accept a 2.5" x 15mm SSD drive.

Product Specifications
Product Name118000130-01 / OB33600
Product TypeSolid State Drive
Drive InterfaceSAS
Drive Width2.5"
Drive Interface Standard12Gb/s SAS
Drive TypeInternal
Storage Capacity800GB
NAND Flash TypeMLC
Internal Operating Temperature0 to 70℃
Maximum Burst Transfer Rate1200MB/s
Max sequential 64KB read/write data transfer rate (MB/s max)1100 / 765
Peak 4KB random read/write command rate (IOPs)130,000/100,000
Sustained 4KB random read/write command rate (IOPs)110,000/30,000
DWPD (Disk Writes Per Day) 10

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: 0B33600 HUSMM1680ASS200

Weight: 0.5 lb

Warranty: 1 Year DiscTech

Brand New

Condition Levels Explained

The product is brand new.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
