EMC VNX V4-VS6FX-800 / 005050784 / 005050783 800GB 6Gbps SAS WI SSD

EMC Part #/MPN: V4-VS6FX-800

DiscTech Item #: EMC-V4-VS6FX-800-NP-OE


Enterprise Grade

Capacity: 800GB

Speed: Solid State Memory

Interface Types: SAS Serial Attached SCSI

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 520

Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps


SSD Endurance DWPD: Enterprise Write Intensive

EMC VNX V4-VS6FX-800 / 005050784 / 005050783 / 118000391-01 800GB 3.5" 6Gbps MLC SAS 520 Write Intensive 10 DWPD Solid State Drive w/ 520BPS tray - New Pull

EMC VNX Series Storage Systems V4-VS6FX-800 / 005050784 / 005050783 / 118000391-01 / HGST Ultrastar SSD800MM HUSMM8080ASS200 / 0B28652 800GB 3.5" 6Gbps MLC SAS 520 WI / Write Intensive 10 DWPD SSD / Solid State Drive w/ 520BPS tray - New Pull


This drive is compatible with EMC servers and storage arrays that accept a 3.5" SAS SSD including the following VNX Series Storage Systems:


EMC VNX V4-VS6FX-800 Specifications
Part Number005050784
Product TypeSolid State Drive
Drive InterfaceSAS
Drive Width3.5"
Drive Interface Standard6Gb/s SAS
Drive TypeInternal
Storage Capacity800GB
NAND Flash TypeMLC
Internal Operating Temperature0 to 70℃
Maximum Burst Transfer Rate600MB/s
Max sequential 64KB read/write data transfer rate (MB/s max)1150 / 700
Peak 4KB random read/write command rate (IOPs)145,000
Sustained 4KB random read/write command rate (IOPs)70,000
DWPD (Disk Writes Per Day)10

ROHS Compliant

Alternate MPNs: 005050784 5050784 005050783 118000391-01 0B28652

Weight: 0.5 lb

Warranty: 1 Year DiscTech

New Pull

Condition Levels Explained

The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
