Fujitsu MHV2040AH 40GB IDE /ATA Hard Drive

FUJITSU Part #/MPN: MHV2040AH

DiscTech Item #: FUJ-MHV2040AH-RF-OE


$59.95
  • Special Order - Ships in 5-10 business days
    Special Order - Ships in 5-10 business days

    This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.

$59.95

Capacity: 40GB

Speed: 5,400RPM

Interface Types: IDE ATA 2.5in IDC44M for laptop

Form Factor: 2.5inx9mm Fits Most laptops

Sector Size: 512 / 512e

Electrical Interface: EIDE Ultra ATA133 133MBps

On-Board Cache: 8MB

Fujitsu MHV2040AH / CA06531-B20000DL / CA26332-B43104BA 40GB 2.5 inches 133Mbps 5.4K RPM IDE / ATA Notebook HDD - Bare Drive - Refurbished

Fujitsu MHV2040AH / CA06531-B20000DL / CA26332-B43104BA 40GB 2.5" 133MB/s Ultra ATA133 5400 RPM IDE / ATA Notebook Hard Disk Drive - Bare Drive - Refurbished

Fits Most Laptops

Alt Model Number: CA06531-B20000DL, CA26332-B43104BA

Mobile Hard Disk Drive

Packing more punch in a small form factor: 2.5-inch hard disk drives pave the way for new possibilities in the mobile market

  • Provides up to 120GB of storage space with 5,400 RPM speed
  • Low power consumption and power-save features help extend battery life
  • RoHS-compliant, eliminating certain hazardous materials in the manufacturing of electronic equipment
  • High speed and storage thresholds can spur a new generation of consumer entertainment applications

Fujitsu is once again proving that less is more. Our latest 2.5-inch mobile hard disk drive offers increased capacity and processing power, yet actually reduces the power needed to do so. Fluid Dynamic Bearing (FDB) motors help limit acoustic noise, resulting in whisper-quiet operation.

What’s more, this pocket-sized drive offers 1.5 ms read/write seek times, while at the same time providing high-capacity, space-efficient storage products to OEMs and resellers.

The history of leadership in research and development by Fujitsu continues to bring innovation to you. The hard disk drives offer up to 120GB storage capacity at 5,400 RPM speeds. This combination can dramatically improve the performance of laptop PCs, small form factor PCs and blade applications.

Clearly, Fujitsu 5,400 RPM mobile hard disk drives are breaking new ground. Leverage 35 years of Fujitsu hard disk drive experience to meet your customers’ insatiable need for mobile flexibility with increased storage capacity. About Fujitsu Computer Products of America, Inc. Fujitsu Computer Products of America, Inc. is a subsidiary of Fujitsu Limited, a leading provider of customer-focused IT and communications solutions for the global marketplace. FCPA provides innovative solutions for the U.S. marketplace. Current product and service offerings include high performance hard disk drives, Magneto-Optical drives, scanners and scanner maintenance, palm vein recognition technology, 10Gb Ethernet switches and degaussers.


Compatibility:

This drive is compatible with any server that accepts 2.5" x 9mm Laptop IDE / ATA Drive.

MOBILE HARD DISK DRIVE
Model NumberMHV2040AH
Specifications
Storage Capacity (formatted)40GB
Bytes/Sector512
Seek Time
  • Track to Track
  • Average
  • Maximum

  • 1.5 ms typ.
  • 12 ms typ. (Read), 14 ms typ. (Write)
  • 22 ms typ.
  • Average latency5.56 ms
    Rotational speed5,400 RPM
    Data transfer to/from host100 MB/s
    InterfaceATA-7
    Buffer size8 MB
    Power Requirements
  • Voltage
  • Spin-up
  • Operating (Read/Write)
  • Idle
  • Standby
  • Sleep

  • 5 V± 5%
  • 1.0 A max
  • 1.9 W typ

  • 0.6 W typ
  • 0.2 W typ
  • 0.1 W typ
  • Dimensions
  • Height
  • Width
  • Depth

  • 9.5mm (0.37in)
  • 70mm (2.8in)
  • 100mm (3.9in)
  • Weight101g (3.56oz) or less
    Ambient Temperature
  • Operating

  • Non-operating

  • Gradient


  • 5° C to 55° C (41° F to 131° F)
  • -40° C to 65° C (-40° F to 149° F)
  • 20° C (68° F) / H or less
  • Realative Humidity
  • Operating

  • Non-operating

  • Max wet bulb

  • 8% to 90% RH (non-condensing)
  • 5% to 95% RH (non-condensing)
  • 29°C (Op.) / 40°C (Non Op.)
  • Vibration
  • Operating

  • Non-operating

  • 9.8 m/s2 (1.0 G) (5 to 500 Hz)
  • 49 m/s2 (5.0 G) (5 to 500 Hz)
  • Shock
  • Operating
  • Non-Operating

  • 2,940 m/s2 (300 G) 2ms
  • 8,820 m/s2 (900 G) 1ms
  • Altitude
  • Operating

  • Non-operating

  • -300 to 3,000 m (-1,000 to 10,000 ft.)
  • -300 to 12,000m (-1,000 to 40,000 ft.)
  • Acoustic noise
  • HDD Ready

  • 28 dBA at 30 cm (typ.), 2.6 bels (typ.)
    Componet Life 5 years or 20,000 POH
    MTBF300,000 POH

    Click here to view the manufacturer's item description/brochure

    ROHS Compliant

    Alternate MPNs: CA06531-B20000DL CA26332-B43104BA

    Weight: 0.5 lb

    Warranty: 1 Year DiscTech

    Refurbished

    Condition Levels Explained

    These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process

    1 Year DiscTech Warranty

    Product Warranties Explained

    The product has a DiscTech warranty for the time period specified. View our limited warranty
