Hitachi Part #/MPN: 0F23082
DiscTech Item #: HIT-0F23082-BN-OE-DEL
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- In Stock:16Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Enterprise Grade
Capacity: 6TB
Speed: 7,200RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 227/202
Average Seek Time: 4.16
Electrical Interface: SATA 600 - 6.0Gbps
On-Board Cache: 128MB
Compatible Systems: Dell 14th Gen. R640/R740, Dell 13th Gen. R730/T630, Dell 12th Gen. R720/T620, Dell 11th Gen. R710/T610
Alt MPN: HUS726060ALE614 908XX 0908XX 0F23082
Hitachi Ultrastar 7K6000 Enterprise Hard Drive
- Best-in-class random & sequential performance
- Reliable, field-proven, 7th generation 5-disk design
- Technology Innovation Improves Storage Efficiency – include higher areal density for 25% faster sequential performance vs. 7K4000, and a 128MB cache buffer
Increasing Capacity Density by 50%
Ultrastar 7K6000 provides 50% more capacity and 30% better power efficiency in terms of Watts per terabyte (W/TB) than its predecessor, Ultrastar 7K4000. The 7K6000 is designed for all traditional and rapidly growing scale-out storage applications, including object, block and file storage architectures, providing huge capacity, the fastest 7,200 RPM performance and the best $/TB acquisition cost.
Technology Innovation Improves Storage Efficiency
Ultrastar 7K6000 also delivers greater storage efficiency through best-in-class performance, achieving up to 3X higher random write performance, thanks to HGST media cache architecture, a disk-based caching technology, which provides a large non-volatile cache on the disk. Media cache also allows for improved reliability and data integrity during unexpected power loss. Other performance-enhancing features include higher areal density for 25% faster sequential performance vs. 7K4000, and a 128MB cache buffer. The 7K6000 offers a 12Gb/s SAS (6Gb/s SATA) interface for easy integration into high performance data centers. As drive capacities increase, so does the time required to recover a failed drive in a RAID configuration. Dramatically reduce RAID rebuild times and maintain system performance during the rebuild process with the new Rebuild Assist
Data Security with Industry-Leading Quality, Reliability
Compliance and privacy requirements drive the need for increased data security. Ultrastar 7K6000 helps protect data from unauthorized use by offering security and encryption options. Instant Secure Erase (ISE) models expedite drive redeployment and retirement. Encryption models protect data with hardware-based encryption, including a Trusted Computing Group (TCG) Enterprise_A, TCG with FIPS 140-2 certification, Level 2. The Ultrastar 7K6000 is a seventh generation, 5-platter design, field proven by top server and storage OEMs, and Internet giants, and extends HGST’s long-standing tradition of reliability leadership with a 2M-hour MTBF rating
Choose Ultrastar 7K6000 for these Enterprise Applications & Environments
- Cloud & Hyperscale storage
- Distributed Files Systems like Ceph™ and Hadoop® to support Big Data Analytics
- Video surveillance & content distribution
- Direct & Network Attached Storage (DAS & NAS)
- RAID arrays
- Massive scale-out data centers (MSO)
Compatibility: This drive is compatible with any server that accepts 3.5in x 1.0in (LFF) SATA drives.
Ultrastar® 7K6000 | |
---|---|
Model/Part No. | 0F23082 908XX |
Alt Model/Part No. | HUS726060ALE614 |
Data Security Mode | Secure Erase (overwrite only) |
Capacity | 6TB/6,000GB |
Interface | SATA 6Gbps |
Form Factor | 3.5-inch |
Sector size (bytes) | 512 |
Performance | |
Data buffer (MB) | 128 |
Rotational speed (RPM) | 7200 |
Latency average, (ms) | 4.16 |
Interface transfer rate (MB/s, max) | 600 |
Sustained transfer rate (MB/s typical) (MiB/sec, typ) (MB/sec, typ) | 216/192 227/202 |
Seek time (read, ms, typical) | 7.6/8.0 |
Reliability | |
Error rate (non-recoverable, bits read) | 1 in 10E15 |
Load/Unload cycles (at 40°C) | 600,000 |
MFBF (M hours) | 2.0 |
Annualized Failure Rate (AFR) | 0.44% |
Availability (hrs/day x days/wk) | 24x7 |
Acoustics | |
Idle (Bels, typical) | 2.9/3.6 |
Power | |
Requirement | +5 V, +12V |
Operating (W, typical) | 9.1 |
Idle (W) | 7.1 |
Power consumption efficiency at idle (Watts/TB) (Watts/GB) | 1.2 0.0012 |
Physical size | |
z-height (mm) | 26.1 |
Dimensions (width x depth, mm) | 101.6 (+/-0.25) x 147 |
Weight (g/lb max) | 715/1.57631 |
Environmental (Operating) | |
Power-On Hours | 5º to 60º C |
Shock (half-sine wave 2 ms, G) | 70 |
Vibration (G RMS 5 to 500 Hz) | 0.67 (XYZ) |
Environmental (Non-Operating) | |
Ambient temperature | -40º to 70º C |
Shock (half-sine wave, 1ms, G) | 300 |
Random vibration (G RMS 5 to 500 Hz) | 1.04 (XYZ) |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: HUS726060ALE614 908XX 0908XX
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
