HGST Hitachi 0B31067 HUSMM1680ASS200 800GB Enterprise MLC SAS SSD
- New PullCondition Levels Explained
The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.
- In Stock:2Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 800GB |
| Speed: | Solid State |
| Interface Types: | SAS |
| Form Factor: | 2.5" SFF Server Drive |
| SSD Endurance DWPD: | Enterprise Write Intensive / WI |
| Electrical Interface: | SAS-3 12Gbps |
Description
HGST Hitachi SSD1600MM 0B31067 HUSMM1680ASS200 Crypto Enabled 800GB 12Gbps 2.5" SFF Enterprise MLC SAS SSD - New Pull
HGST Enterprise Storage
Experience HGST leverages decades of proven enterprise storage expertise in Serial Attached SCSI (SAS) design, reliability, firmware, customer qualification and system integration to the Ultrastar® SSD1600MM solid-state drive (SSD) family. The synergistic relationship between HGST’s throughput-enhancing SSDs and traditional HDDs provides cost effective, end-to-end enterprise-class storage solutions, delivering reliability, compatibility, capacity, cost and system performance. This combination makes HGST a leading SSD/HDD provider with the experience and technology needed to meet escalating reliability, endurance and performance in the most demanding enterprise environments.
Maximum Performance,
Reliability and Endurance The Ultrastar SSD1600MM delivers high sequential throughput, up to 1100MB/s read and 765MB/s write (12Gb/s SAS). It also delivers up to 130,000 read and 100,000 write IOPS, reaching speeds >100 times faster than HDDs and double the speed of current 6Gb/s SSDs, allowing rapid access to “hot” enterprise data for improved productivity and operational efficiency. The Ultrastar SSD1600MM family offers significant value in terms of IOPS per Watt, while reducing total cost of ownership (TCO) through low power consumption, efficient cooling and reduced space requirements.
Compatibility:
This drive is compatible with enterprise grade servers and storage arrays that accept a 2.5" x 15mm SSD drive.
Specifications
| Product Specifications | |
|---|---|
| Product Name | SSD1600MM |
| HGST Model | HUSMM1680ASS200 |
| HGST Part No. | 0B31067 |
| Product Type | Solid State Drive |
| Drive Interface | SAS |
| Drive Width | 2.5" |
| Drive Interface Standard | 12Gb/s SAS |
| Drive Type | Internal |
| Storage Capacity | 800GB |
| NAND Flash Type | MLC |
| Internal Operating Temperature | 0 to 70℃ |
| Performance | |
| Maximum Burst Transfer Rate | 1200MB/s |
| Max sequential 64KB read/write data transfer rate (MB/s max) | 1100 / 765 |
| Peak 4KB random read/write command rate (IOPs) | 130,000/100,000 |
| Sustained 4KB random read/write command rate (IOPs) | 110,000/30,000 |
| Reliability | |
| DWPD (Disk Writes Per Day) | 10 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: HUSMM1680ASS200
Weight: 0.5 lb
Warranty: 1 Year DiscTech
Condition
New Pull
Warranty
1 Year DiscTech Warranty
