HP 792243-001 792368-001 SDLFNDAR-480G-1H14 480GB 2.5in SFF 6Gbps MLC SATA SSD kit
- In Stock:1Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 480GB |
| Speed: | Solid State |
| Interface Types: | SATA |
| Form Factor: | 2.5" x 7mm Fits All laptops |
| SSD Endurance DWPD: | Enterprise Read Intensive / RI |
| Electrical Interface: | SATA 600 - 6Gbps |
Description
HP 480GB 2.5" 6.0 Gb/s Multi-Level Cell Read Intensive 1 Drive Write Per Day Serial Attached Technology Attachment Solid State Disk Drive
Optimized for enterprise server and cloud computing environments. CloudSpeed Ascend SSDs are ideally suited for readintensive applications such as, File Servers, Web-based Applications and Virtual Tape Libraries (VTL).
This SSD is with 6Gb/s SATA interface and provide data transfer rates up to 450/400 MB/s** sequential read/write and performance up to 80K/15K IOPS random read/write. CloudSpeed Ascend SSDs offer high data integrity by employing a combination of powerful error correction and detection, full data path protection, thermal monitoring, and data fail recovery.
Read-Intensive Application Workloads
- File Servers
- Web-based Applications
- Virtual Tape Libraries (VTL)
HP Model: VK0480GEQNB
ALT MP/N: 792368-001 792243-001 791146-001 SDLFNDAR-480-1H14 SXBLFA
Compatibility
This drive is compatible with laptops, workstations, desktops, and servers / SANs that accept 2.5" x 7mm (Thin/Case) SATA drives.
Specifications
| VK0480GEQNB | |
|---|---|
| Part Number | 792243-001 |
| Alternate Part Number | 792368-001 791146-001 SDLFNDAR-480-1H14 SXBLFA |
| Model | SXBLFA |
| Performance | |
| Interface | SATA 6Gb/s |
| Sequential Read/Write (MB/s) | Up to 450/400 MB/s |
| Random Read/Write (IOPS) | Up to 80K/15K IOPS |
| Access Time | <2.0 ms/td> |
| 19nm MLC User Capacities | 480 GB/td> |
| Reliability | |
| Data Reliability (BER) | 1 unrecoverable error in 10^17 bits read |
| MTBF | 2.5M hours |
| Data Fail Recovery | Recover up to 1 NAND flash erase block of data |
| Power Fail Recovery | High-reliability backup-power circuitry |
| Temperature Monitoring | Performance throttling upon warning/critical temperature |
| Endurance | 1DWPD |
| Power | |
| Vcc | 5V ± 5% |
| Active (Typ) | 5.2W |
| Idle | 2.2W |
| Environmental | |
| Shock (operating) | 1000g @ 1.0 msec, 1 shock along each axis, X, Y, Z, in each direction |
| Vibration (operating) | 2.17 g rms 7-800 Hz |
| Operating Temperature | 0° C to 70° C (internal) |
| Storage Temperature | -40° C to 95° C |
| Humidity | 5% to 95%, non-condensing, relative humidity |
| Altitude | -200 feet to 10,000 feet |
| Mechanical | |
| Length | 100.2 mm |
| Width | 69.85 |
| Height | 7 mm |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: VK0480GEQNB 792368-001 791146-001 SDLFNDAR-480-1H14 792241-B21
Weight: 1 lb
Warranty: 1 Year DiscTech
Condition
The product is brand new.
Warranty
1 Year DiscTech Warranty
