SAMSUNG Part #/MPN: MZ-XLR9600
DiscTech Item #: SAM-MZ-XLR9600-BN-OE-HPI
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- In Stock:14Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Enterprise Grade
Capacity: 960GB
Speed: Solid State Memory
Interface Types: NVMe U.3, NVMe U.2, PCIe
Form Factor: 2.5inx15mm SFF Server Drive
Sector Size: 512 / 512e
Sustained Throughput: 7000 / 3500
Electrical Interface: PCIe - v4.0 - 32GBps
SSD Type: TLC
SSD Endurance DWPD: Enterprise Read Intensive
U.3 drives are backwards compatible with U.2 systems
Alt PN: MZXLR960HBHQ-00AH3 / MZXLR960HBHQ-000H3
Compatibility:
This drive is compatible with servers and arrays that accept 2.5” 15mm U.2/U.3 SFF PCIe NVMe drives
| Samsung® SSD PM1733 Series | |
|---|---|
| Model Number | MZ-XLR9600 / MZXLR960HBHQ-000H3 |
| Essentials | |
| Product Collection | Samsung PM1733 NVMe SSD |
| Form Factor | U.3 15mm |
| Capacity | 960GB |
| Lithography Type | Samsung 3D V-NAND |
| Use Conditions | Server/Enterprise |
| PERFORMANCE | |
| Sequential Read | (up to) 7000 MB/s |
| Sequential Write | (up to) 3500 MB/s |
| 4K Random Read | up to 1.5M IOPS |
| 4K Random Write | up to 135k IOPS |
| Operating Temperature Range | 0°C to 70°C |
| Mean Time Between Failures (MTBF) | 2 million hours |
| Endurance | 1 DWPD for 5 years |
| Encryption Supported | TCG Opal 2.0 |
| Bytes per sector | 512, 520, 4096, 4104, 4160 Bytes |
| PACKAGE SPECIFICATIONS | |
| Physical dimensions | 100.2 mm x 69.9 mm x 14.8 mm |
| Interface | PCIe Gen 4.0 x 4 |
| Manageability | NVMe-MI 1.0a compliant |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: PM1733 MZXLR960HBHQ-00AH3 MZXLR960HBHQ-000H3 P36976-001
Weight: 1 lb
