Hewlett Packard 410916-B21 Cisco Catalyst 3020 Blade Switch Module

HEWLETT PACKARD Part #/MPN: 410916-B21

DiscTech Item #: HPI-410916-B21-RF-OE


Interface Types: Ethernet RJ45

Electrical Interface: Ethernet Gigabit - 1Gbps

Bays/Ports/Slots: 8

Voltage: 12V

Hewlett Packard 410916-B21 Cisco Catalyst 3020 Blade Switch Module for c-Class BladeSystem - Refurbished

Hewlett Packard 410916-B21 Cisco Catalyst 3020 Blade Switch Module for c-Class BladeSystem - Refurbished


The Cisco Catalyst Blade Switch 3020 for HP c-Class BladeSystem provides HP customers with an integrated switching platform providing Cisco resiliency, advanced security and enhanced manageability to the server edge while dramatically reducing cabling requirements. The Catalyst Blade Switch 3020 capitalizes on your current Cisco network infrastructure to reduce the total cost of implementation and ownership. By utilizing the advanced Cisco end-to-end management framework, customers can simplify current and future deployments reducing implementation and management costs. Flexible to fit your needs - The Catalyst Blade Switch 3020 is designed with sixteen internal 1Gb downlinks and eight 1Gb RJ-45 copper uplinks. Up to four uplinks can be optionally configured as fiber SX links. Two uplinks can optionally be configured as internal cross-connects.


c-Class BladeSystem

Model Number410916-B21
Product LineCatalyst
Product Model3020
Height (in/mm)1.1/27.94
Width (in/mm)7.5/190.5
Depth (in/mm)10.5/266.7
Weight (lb/g)2.80/1270.06
Standard Memory128 MB
Input Voltage12 V DC
Green Compliance Certificate/AuthorityWEEE
Network Technology10Base-T 10/100/1000Base-T
Ethernet TechnologyGigabit Ethernet
Number of Network (RJ-45) Ports8
CategorySwitches & Bridges
Number of Total Expansion Slots4
Green CompliantYes
Media Type SupportedTwisted Pair
Layer Supported3
Expansion Slot TypeSFP

Click here to view the manufacturer's item description/brochure

Alternate MPNs: WS-CBS3020-HPQ

Weight: 2 lb

Warranty: 1 Year DiscTech


Condition Levels Explained

These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
