Hitachi Ultrastar 15K450 0B23318 / HUS154530VLS300 Serial SCSI / SAS Hard Drive

Hitachi Part #/MPN: 0B23318

DiscTech Item #: HIT-0B23318-BN-3Y


$199.00
  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

$199.00

Enterprise Grade

Capacity: 300GB

Speed: 15,000RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 98 - 160

Average Seek Time: 3.6

Electrical Interface: SAS-1 Serial Attached SCSI - 3.0Gbps

On-Board Cache: 16MB

Compatible Systems: Dell 10th Gen. 2950 / 6950

Hitachi Ultrastar 15K450 0B23318 / HUS154530VLS300 300GB 15K RPM 3.0Gbps Serial SCSI / SAS Hard Drive - Brand New

Ultimate performance meets high capacity

Hitachi’s next-generation 3.5-inch 15,000 RPM enterprise class hard drive delivers the performance and reliability required in mission-critical non-stop computing environments. Built upon the mature system architecture and electronics of the prior generation, the Ultrastar™ 15K450 provides up to a spacious 450GB capacity, 16MB cache and a choice of Serial Attached SCSI (SAS) 3Gb/s or Fibre Channel Arbitrated Loop (FCAL) 4Gb/s interfaces. These features make the Ultrastar 15K450 the ideal solution for demanding enterprise computing environments like online transaction processing, intensive data analysis and multi-user applications. The mature design of Ultrastar 15K450 helps ensure shorter qualification time.

Highest reliability for demanding environments

Important reliability features come standard in the Ultrastar 15K450. Rotational Vibration Safeguard (RVS) technology ensures drive performance in multi-drive systems where rotational vibration is likely to occur. Hitachi-patented Thermal Fly-height Control (TFC) technology maintains a consistent fly-height during the read/write process ensuring a better soft error rate, while end-to-end data protection enhances error detection for optimal data integrity. Finally, Hitachi offers the only enterprise-class hard drive utilizing a head load/unload ramp to help minimize drive failures as a result of handling during integration.

Proven PMR technology

The Ultrastar 15K450 is the first enterprise-class drive from Hitachi to use Perpendicular Magnetic Recording (PMR) technology. PMR has already been in use across the company’s mobile and desktop product lines and has been proven ready for the demanding mission-critical server and storage applications in the enterprise environment.


Compatibility:

All SAS compatible servers including:
Dell PowerEdge 1900, 1950, 2900, 2950, 6900, 6950. PowerVault MD1000 and MD3000.

Drive specification

0B23318 / HUS154530VLS300

Formatted Gbytes (512 bytes/sector)

300

Bytes per sector

512

Read/write heads

8

Data Disks

4

Areal density (Gbits/inch2 avg)

183

Spindle speed (RPM)

15,000

I/O data transfer rate (Mbytes/sec max)

300

Cache buffer

16 Mbytes

Height (max)

25.8 mm

Width (max)

101.6 mm

Length (max)

146.2 mm

Weight (max) grams

750

Average seek, read (msec typical)

3.6


Click here to view the manufacturer's item description/brochure

Alternate MPNs: HUS154530VLS300

Weight: 1.8 lb

Warranty: 3 Year Manufacturer

Brand New

Condition Levels Explained

The product is brand new.

3 Year Manufacturer Warranty

Product Warranties Explained

The product has a manufacturer warranty for the time period specified.
