Hitachi 0B23661 HUS156030VLS600 SAS Hard Drives
- Brand NewCondition Levels Explained
The product is brand new.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 300GB |
| Speed: | 15K RPM |
| Interface Types: | SAS |
| Form Factor: | 3.5" LFF Hard Drive |
| Electrical Interface: | SAS-2 6Gbps |
| RAM: | 64MB |
Description
Hitach Ultrastar 15K450 300GB 15K RPM 6.0Gbps Serial SCSI / SAS Hard Drive 0B23661 / HUS156030VLS600 - Brand New
Ultrastar™ 15K450
The all-in-one enterprise drive delivers performance and capacity in one package
Combines ultimate performance with high capacity in the same drive. The 6Gb/s Serial Attached SCSI (SAS) and 4Gb/s Fibre Channel Arbitrated Loop (FCAL) interfaces support the reliability required in the most demanding enterprise computing environments.
Hitachi Part Numbers: 0B23661 / HUS156030VLS600
Compatibility
All SAS compatible servers including:
Dell PowerEdge 1900, 1950, 2900, 2950, 6900, 6950. PowerVault MD1000.
Specifications
| Hitachi Ultrastar 15K450 HUS156030VLS600 | |
| Device Type | Hard drive - internal |
| Approximate Width | 4 in |
| Approximate Depth | 5.7 in |
| Approximate Height | 1 in |
| Approximate Weight | 1.7 lbs |
| Hard Drive | |
| Form Factor | 3.5" x 1/3H |
| Capacity | 300 GB |
| Interface Type | Serial ATA-600 / SAS |
| Buffer Size | 64 MB |
| Features | Fluid Dynamic Bearing (FDB) motor, load/unload technology, Rotational Vibration Safeguard (RVS) |
| Performance | |
| Drive Transfer Rate | 600 MBps (external) |
| Seek Time | 3.4 ms (average) |
| Average Latency | 2 ms |
| Spindle Speed | 15000 rpm |
| Reliability | |
| MTBF | 1,600,000 hour(s) |
| Non-Recoverable Errors | 1 per 10^16 |
| Expansion / Connectivity | |
| Interfaces | 1 x Serial ATA-600 |
| Compatible Bays | 1 x internal - 3.5" x 1/3H |
| Miscellaneous | |
| Compatible with Windows 7 | "Compatible with Windows 7" software and devices carry Microsofts assurance that these products have passed tests for compatibility and reliability with 32-bit and 64-bit Windows 7. |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 131 °F |
| Shock Tolerance | 30 g @ 2ms half-sine pulse (operating) / 250 g @ 2ms half-sine pulse (non-operating) |
| Vibration Tolerance | 1.5 g @ 5-500 Hz (operating) / 2 g @ 5-500 Hz (non-operating) |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: HUS156030VLS600
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Condition
Brand New
Warranty
1 Year DiscTech Warranty
