Hitachi Ultrastar SSD800MM Type UCMSSS40M HUSMM8040ASS200 / 0B28588 400GB SAS SSDM

Hitachi Part #/MPN: 0B28588

DiscTech Item #: HIT-0B28588-C9-OE


$695.00
$695.00

Enterprise Grade

Capacity: 400GB

Speed: Solid State Memory

Interface Types: SAS Serial Attached SCSI

Form Factor: 2.5inx15mm SFF Server Drive

Sector Size: 512 / 512e

Sustained Throughput: 1100/700

Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps

SSD Type: MLC

SSD Endurance DWPD: Enterprise Mixed Use

Hitachi Ultrastar SSD800MM Type UCMSSS40M HUSMM8040ASS200 / 0B28588 400GB 2.5 inch 12Gbps MLC Mix Mode SAS SSD


Ultrastar® SSD800MM ENTERPRISE SOLID-STATE DRIVES

Maximum Performance, Reliability and Endurance
The Ultrastar SSD800MM delivers high sequential throughput, up to 1100MB/s read and 700MB/s write (12Gb/s SAS). It also delivers up to 145,000 read and 70,000 write IOPS, reaching speeds >100 times faster than HDDs and double the speed of current 6Gb/s SSDs, allowing rapid access to “hot” enterprise data for improved productivity and operational efficiency. The Ultrastar SSD1600MR family offers significant value in terms of IOPS per Watt, while reducing total cost of ownership (TCO) through low power consumption, efficient cooling and reduced space requirements.

The Ultrastar SSD800MM family combines enterprisegrade MLC NAND Flash memory, advanced endurance management firmware and power loss data management techniques to extend reliability, endurance and sustained performance over the life of the SSD. The Ultrastar SSD800MM family achieves an extraordinary 0.35% annual failure rate (AFR) or 2.5 million hour meantime-between-failure (MTBF). The 1920GB capacity model endures up to 10.5 Petabytes (PB) of random writes over the life of the drive—the equivalent of writing 5.8 Terabytes (TB) per day for five years.

For complete end-to-end data protection and reliability, the Ultrastar SSD1600MR family incorporates the T10 Data Integrity Field (DIF) standard, extended error correction code (ECC), Exclusive-OR (XOR) parity to protect against Flash die failure, parity-checked internal data paths without an external write cache, and an exclusive power loss data management feature that does not require supercapacitors. The Ultrastar SSD1600MR family is backed by a five year limited warranty, or the maximum Petabytes (PB) written (based on capacity).

HGST Enterprise Storage Experience
HGST leverages decades of proven enterprise storage expertise in Serial Attached SCSI (SAS) design, reliability, firmware, customer qualification and system integration to the Ultrastar® SSD800MM solid-state drive (SSD) family. The synergistic relationship between HGST’s throughput-enhancing SSDs and traditional HDDs provides cost effective, end-to-end enterprise-class storage solutions, delivering reliability, compatibility, capacity, cost and system performance. This combination makes HGST a leading SSD/HDD provider with the experience and technology needed to meet escalating reliability, endurance and performance in the most demanding enterprise environments.

HGST Quality and Service
HGST’s Ultrastar SSD800MM family extends the company’s long-standing tradition of performance and reliability leadership. A balanced combination of new and proven technologies enables high reliability and availability to customer data.

HGST drives are backed by an array of technical support and services, which may include customer and integration assistance. HGST is dedicated to providing a complete portfolio of SSD/HDD solutions to satisfy today’s monumental computing needs.

Highlights

  • MLC NAND Flash for ultra-high performance and endurance
  • 10 DWPD for 5 years
  • Best IOPS/Watt for reduced TCO
  • 12Gb/s SAS interface for maximum throughput
  • Advanced power loss data management technology
  • Self-encrypting models conform to TCG’s Enterprise specification

Applications/Environments

  • Ultra-high performance tier-0 read endurance enterprise storage
  • Enterprise-class servers and high performance computing
  • Space and/or power constrained environments
  • Online Transaction Processing (OLTP)
  • Video pre- and post-production
  • Cloud computing


Compatibility:

This drive is compatible with laptops that accept 2.5" x 15mm SFF SAS drives.

Ultrastar® SSD1600MR
Model NumberHUSMM8040ASS200
Alt Model Number0B28588
InterfaceSAS 12Gb/s
Capacity (GB) at 512 bytes/sector400GB
Form Factor2.5-Inch
Flash memory technologyMulti Level Cell (MLC)
Sector size support512, 520, 528, 4K
Performance
Read throughput (max MB/s, sequential 64K)1100
Write throughput (max MB/s, sequential 64K)700
Read IOPS (max IOPS, random 4K)145,000
Write IOPS (max IOPS, random 4k)70,000
Reliability
Error rate (non-recoverable bits read)1 in 10^17
MTBF (M hours)2.5
Annual failure rate (AFR)0.35%
Availability (hrs/day x days/wk)24x7
Endurance (max PB, random write)2.92
Power
Requirement+5 VDC (+/-5%)
+12 VDC (+/-5%)
Operating (W, typical)9.0 and 11.0
Idle (W)2.2
Physical
z-height (mm)15.0
Dimensions (width x depth, mm)70.1 x 100.6
Weight (g, max)187
Environmental (operating)
Case temperature0º to 70ºC
Shock (half-sine wave)1000G (0.5ms)
500G (2ms)
Vibration, random (G RMS)2.16, all axis (5 to 700 Hz)

ROHS Compliant

Alternate MPNs: HUSMM8040ASS200

Weight: 0.5 lb

Warranty: 1 Year DiscTech

Certified 95

Condition Levels Explained

These products can not qualify as new, however, we have tested and evaluated their health, performance and usage statistics and determined that they have at least 95% of their designed service life remaining. e.g. in SSDs they are guaranteed to have at least 95% endurance remaining.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
