Hitachi 0F14689 3TB SATA HDD

HGST Part #/MPN: 0F14689

DiscTech Item #: HIT-0F14689-NP-OE


$99.00
  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

$99.00

Enterprise Grade

Capacity: 3TB

Speed: 7,200RPM

Interface Types: SATA

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 181

Average Seek Time: 8.0

Electrical Interface: SATA 600 - 6.0Gbps

On-Board Cache: 64MB

Hitachi Ultrastar 7K4000 0F14689 / HUS724030ALA640 3TB 6Gbps 7.2K Enterprise SATA HDD - New Pull

Hitachi Ultrastar 7K4000 0F14689 / HUS724030ALA640 3TB / 3000GB 6.0Gbps 7,200 RPM Enterprise Serial ATA HDD - New Pull

Ultrastar® 7K4000 3.5-Inch Enterprise 7200 RPM Hard Disk Drives

Delivering Industry-Leading Quality and Reliability - HGST Ultrastar® 7K4000 is the world’s first 3TB 7200 RPM hard drive with a 2.0 million hours MTBF specification. Ultrastar 7K4000 represents the sixth-generation HGST 5-platter design, which has been field proven by top server and storage OEMs and Internet giants. Engineered for the highest quality, the Ultrastar 7K4000 is put through grueling design tests during development and must pass stringent ongoing reliability testing during manufacturing. Ultrastar 7K4000 delivers by reducing downtime, eliminating service calls and minimizing TCO.

Increasing Capacity Density by One Third - To deal with the explosive petabyte (PB) growth, data centers require large amounts of efficient storage. Reducing W/GB without expanding floor space is vital to lowering operating costs. To meet these demands, Ultrastar 7K4000 delivers 33% more capacity in the same footprint at 24% lower W/GB than its predecessor, Ultrastar 7K3000. Now you can get 2.4PB in the footprint of a standard 19-inch enterprise storage rack by stacking ten 4U, 60-bay enclosures. Ultrastar 7K4000 dual port SAS is available in traditional 512, 520 and 528 byte sector size. Ultrastar 7K4000 SATA is an Advanced Format drive, using 4096-byte sector size to provide enormous capacity earlier than otherwise possible for environments optimized for this technology. Advanced Format drives are backwards compatible with legacy 512-byte sector size by offering built-in 512-byte emulation through the SATA interface.

Combining 7200 RPM Performance and Granular Power Control - Operating at 7200 RPM, Ultrastar 7K4000 offers better overall performance than slower RPM capacity-oriented drives, and does so at impressively low power-consumption rates. The Ultrastar 7K4000 can help data centers achieve lower AC power and HVAC requirements. With five Advanced Power Management modes,the 7K4000 achieves a 59% reduction in watts during low RPM idle mode, and uses less than 2W during standby/sleep modes, freeing up precious headroom for growing enterprise needs.

Innovating for a More Sustainable Environment - The Ultrastar 7K4000, with its halogen-free design and power-efficient operation, qualifies for the HGST EcoTrac classification, which identifies products that minimize environmental impact in the areas of product design, manufacturing, operation and disposal.

Highlights

  • 2.0 million hours MTBF1
  • Up to 4 terabytes2 of capacity
  • SATA 6Gb/s and SAS 6Gb/s models for configuration flexibility
  • Advanced Format SATA with 512-byte emulation (512e)
  • Dual Stage Actuator (DSA) and Enhanced Rotational Vibration Safeguard (RVS) for robust performance in multi-drive environments
  • 24x7 accessibility for enterprise-class, capacity-optimized applications

Applications/Environments

  • Cloud storage
  • Massive Scale Out (MSO)
  • Data warehousing & mining
  • Disk-to-disk backup & archiving
  • RAID arrays
  • Network Attached Storage (NAS)


Compatibility:

This drive is compatible with any server that accepts 3.5"x1.0" (LFF) SATA drives.

SPECIFICATIONS
Model Number0F14689
Alt Model NumberHUS724030ALA640
CONFIGURATION
InterfaceSATA 6Gb/s
Formatted Capacity (GB) at 512 bytes/sector3TB/3000GB
Form Factor3.5-inch
Sector size (bytes)512n
Max. areal density (Gbits/sq. in)475
PERFORMANCE
Data buffer (MB)64
Rotational speed (RPM)7200
Interface transfer rate (MB/s, max)600
Sustained transfer rate (MB/s. typical)181
Seek Time (read, ms, typical)8.0
RELIABILITY
Error rate (non-recoverable , bits read)1 in 10e15
Load/Unload cycles (at 40°C)600,000
Availability (hrs/day x days/wk)24x7
MTBF (M hours)2.0
ACOUSTICS
Idle (Bels, typical)2.9
POWER
Requirements+5 VDC(+/-5%)
+12VDC(+10%*-8%)
Start up current (A, max)1.2 (+5V)
2.0 (+12V)
Read/write (W)11.4
Idle (W, avg)6.9
Unload idle (W)5.7
PHYSICAL SIZE
z-Height (in/mm)1.0275/26.1
Width (in/mm)4.0098/101.85
Depth (in/mm)5.7874/147
Weight (lb./g)1.52119/690

Click here to view the manufacturer's item description/brochure

Alternate MPNs: HUS724030ALA640

Weight: 1.8 lb

Warranty: 1 Year DiscTech

New Pull

Condition Levels Explained

The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
