Hitachi 0F14989 3TB SATA Hard Drive

Hitachi Part #/MPN: HX1GT

DiscTech Item #: HIT-0F14989-RF-OE-DEL


$40.00
$40.00

Enterprise Grade

Capacity: 3TB

Speed: 7,200RPM

Interface Types: SATA

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 157

Average Seek Time: 8.2

Electrical Interface: SATA 600 - 6.0Gbps

On-Board Cache: 64MB

Hitachi Ultrastar 7K3000 0F14989 HX1GT 3TB 3.5" 6Gbps 7.2K RPM Enterprise SATA Hard Drive - Refurbished OEM

Hitachi Ultrastar 7K3000 0F14989 3TB / 3000GB 3.5" 6Gb/s 7200 RPM Enterprise 512 Serial Attached Technology Attachment HDD - Refurbished OEM

Ultrastar™ 7K3000
3.5-Inch Enterprise 7200 RPM Hard Disk Drives

Delivering Industry-leading Quality and Reliability
The HGST Ultrastar™ 7K3000 is the world’s first and only 7200 RPM hard drive rated at 2.0 million hours MTBF and backed by a five-year limited warranty. The Ultrastar 7K3000 represents the fifth-generation HGST 5-platter mechanical design, first introduced in 2004, and has been field proven by top server and storage OEMs as well as leading Internet giants. When the highest quality and reliability are a top requirement, customer field data proves that the Ultrastar 7K3000 delivers by reducing downtime, eliminating service calls and keeping TCO to a minimum. Engineered for the highest reliability, the Ultrastar 7K3000 is not only put through grueling design tests during development but must also pass stringent ongoing reliability testing during manufacturing. Across the entire Ultrastar family, world-class quality control, combined with scientific root-cause analysis and multi-faceted corrective actions, ensure that HGST remains the recognized leader in quality and reliability for enterprise-class hard drives.

Increasing Capacity Density by 50%
Recent measures such as data de-duplication and thin provisioning have not been able to stem the explosive petabyte (PB) growth requirements in cloud storage and data centers. Pervasive Internet computing with remotely stored email, pictures and social media, all being accessed from light-weight tablet and notebook computers, is changing consumer expectations. Ongoing worldwide government data retention regulations and security requirements are also driving up data center and private cloud storage needs. At the same time, tile space and megawatts remain at a premium, while in some highly built-out metropolitan areas both are at an absolute “no-growth” state. To meet these demands, the Ultrastar 7K3000 delivers 50% more capacity in the same footprint and does so at a 32% reduction in watts/GB versus our prior generation Ultrastar A7K2000 product. It is now possible to achieve a colossal 1.8 PB in the footprint of a standard 19-inch enterprise storage rack by stacking ten 4U, 60-bay enclosures.

Offering Choices of Interface and Encryption
The HGST Ultrastar 7K3000 is the first HGST 7200 RPM drive available in both 6Gb/s SATA and 6Gb/s SAS interfaces and also available in two encryption options. The Ultrastar 7K3000 SATA model integrates easily with legacy SATA and Fibre Channel to SATA environments. The Ultrastar 7K3000 SATA model is available with a bulk data encryption (BDE) option. The Ultrastar 7K3000 dual-port SAS model is targeted at emerging 6Gb/s SAS enterprise infrastructure and is available with industry standard TCG Enterprise A encryption. When enabled, both of these hardware-based implementations encrypt all data on the drive using a private security key as it is written to the disk, and then decrypt it with the key as it is retrieved, giving users an extreme level of data protection. These security options not only protect sensitive data but also reduce the time and effort involved in re-deploying hard drives since without the key , the data is unrecoverable.

Combining 7200 RPM Performance and Granular Power Control
Operating at 7200 RPM, the HGST Ultrastar 7K3000 offers better overall performance than slower RPM capacity-oriented drives, and does so at impressively low power consumption rates. When compared to HGST’s previous generation Ultrastar A7K2000, the 7K3000 is up to 3 times faster in sustained data transfer rates. The Ultrastar 7K3000 can help data centers achieve lower AC power and HVAC requirements. With five Advanced Power Management modes, the Ultrastar 7K3000 achieves a 59% reduction in watts during low RPM idle mode, and uses less than 1W during standby/sleep modes, freeing up precious headroom for growing enterprise needs.

Innovating for a More Sustainable Environment
The Ultrastar 7K3000 demonstrates HGST ecological leadership with its halogen-free design and power-efficient operation. Both these features serve to qualify the drive forth HGST EcoTrac classification, which identifies products that minimize environmental impact in the areas of product design, manufacturing, operation and disposal.

HGST Quality and Service
HGST’s Ultrastar 7K3000 extends the company’s long-standing tradition of performance and capacity leadership. The proven drive design enables high reliability and availability to customer data. Ultrastar quality, performance and world class technical support and service provides customers with a lower total cost of ownership over previous generations.

HGST drives are backed by an array of technical support and services, which may include customer and integration assistance. HGST is dedicated to providing a complete portfolio of HDD/SSD solutions to satisfy today’s monumental computing needs.

Highlights

  • 2.0 million hours MTBF
  • Up to 3 terabytes2 of capacity
  • SATA 6Gb/s and SAS 6Gb/s models for configuration flexibility
  • Dual Stage Actuator (DSA) and Enhanced Rotational Vibration Safeguard (RVS) for robust performance in multi-drive environments
  • 24x7 accessibility for enterprise-class, capacity-optimized applications

Applications/Environments

  • Cloud storage
  • Massive Scale Out (MSO)
  • Data warehousing & mining
  • Disk-to-disk backup & archiving
  • RAID arrays
  • Network Attached Storage (NAS)

Alt Model Number: HUA723030ALA640
Dell Model Number: HX1GT, 0HX1GT


Compatibility:

This drive is compatible with any server that accepts 3.5in x 1.0in (LFF) SATA drives.

Ultrastar 7K3000
Model/Part No.0F14989
Alt Model/Part No.HUA723030ALA640
Dell Model/Part No.HX1GT
Configuration
InterfaceSATA 6Gb/s
Capacity (GB) at 512 Bytes/sector3TB / 3,000GB
Form Factor3.5-inch
Sector size (bytes)512
Max. areal density (Gbits/sq. in)369
Performance
Data buffer (MB)64
Rotational speed (RPM)7200
Interface transfer rate (MB/sec, max)600
Sustained transfer rate (MB/sec, typical)157
Seek time (read, ms, typical)8.2
Reliability
Error rate (non-recoverable, bits read)1 in 10^15
Load/unload cycles (at 40° C)600,000
Availability (hrs/day x days/wk)24x7
MTBF (M hours)2.0
Acoustics
Idle (Bels, typical)2.9
Power
Requirement+5 VDC (+/-5%)
+12VDC (+10%/-8%)
Startup current (A, max.)1.2 (+5V), 2.0 (+12)
Read/write (W)11.3
Unload idle (W)5.6/td>
Physical size
z-height (mm)26.1
Dimensions (width x depth, mm)101.6 (+/-0.25) x 147
Weight (g, max)690
Environmental (operating)
Ambient temperature5o to 60o C
Shock (half-sine wave 2 ms, G)70
Vibration (G RMS, 5 to 500 Hz)0.67 (XYZ)
Environmental (non-operating)
Ambient temperature-40° to 70°C
Shock (half-sine wave, G)300

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: 0F14989 HUA723030ALA640 0HX1GT

Weight: 1.5 lb

Warranty: 1 Year DiscTech

Refurbished

Condition Levels Explained

These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
