Hitachi Part #/MPN: HUS726040ALS214
DiscTech Item #: HIT-HUS726040ALS214-RF-OE
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Special Order - Ships in 5-10 business daysSpecial Order - Ships in 5-10 business days
This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
Enterprise Grade
Capacity: 4TB
Speed: 7,200RPM
Interface Types: SAS Serial Attached SCSI
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 202
Average Seek Time: 4.16
Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps
On-Board Cache: 128MB
Hitachi Ultrastar 7K6000 0F22941 / 0F22968 / 0F22959 / HUS726040ALS210 / HUS726040ALS214 4TB / 4000GB 12Gbps 7200 RPM 512 Native Enterprise SAS / Serial Attached SSCI Hard Disk Drive - Refurbished
Alt MPN: HUS726040ALS214, HUS726040ALS210, 0F22941, 0F22959
Hitachi Ultrastar 7K6000 Enterprise Hard Drive
- Best-in-class random & sequential performance
- Reliable, field-proven, 7th generation 5-disk design
- Technology Innovation Improves Storage Efficiency – include higher areal density for 25% faster sequential performance vs. 7K4000, and a 128MB cache buffer
Increasing Capacity Density by 50%
Ultrastar 7K6000 provides 50% more capacity and 30% better power efficiency in terms of Watts per terabyte (W/TB) than its predecessor, Ultrastar 7K4000. The 7K6000 is designed for all traditional and rapidly growing scale-out storage applications, including object, block and file storage architectures, providing huge capacity, the fastest 7,200 RPM performance and the best $/TB acquisition cost.
Technology Innovation Improves Storage Efficiency
Ultrastar 7K6000 also delivers greater storage efficiency through best-in-class performance, achieving up to 3X higher random write performance, thanks to HGST media cache architecture, a disk-based caching technology, which provides a large non-volatile cache on the disk. Media cache also allows for improved reliability and data integrity during unexpected power loss. Other performance-enhancing features include higher areal density for 25% faster sequential performance vs. 7K4000, and a 128MB cache buffer. The 7K6000 offers a 12Gb/s SAS (6Gb/s SATA) interface for easy integration into high performance data centers. As drive capacities increase, so does the time required to recover a failed drive in a RAID configuration. Dramatically reduce RAID rebuild times and maintain system performance during the rebuild process with the new Rebuild Assist
Compliance and privacy requirements drive the need for increased data security. Ultrastar 7K6000 helps protect data from unauthorized use by offering security and encryption options. Instant Secure Erase (ISE) models expedite drive redeployment and retirement. Encryption models protect data with hardware-based encryption, including a Trusted Computing Group (TCG) Enterprise_A, TCG with FIPS 140-2 certification, Level 2. The Ultrastar 7K6000 is a seventh generation, 5-platter design, field proven by top server and storage OEMs, and Internet giants, and extends HGST’s long-standing tradition of reliability leadership with a 2M-hour MTBF rating
Choose Ultrastar 7K6000 for these Enterprise Applications & Environments
- Cloud & Hyperscale storage
- Distributed Files Systems like Ceph™ and Hadoop® to support Big Data Analytics
- Video surveillance & content distribution
- Direct & Network Attached Storage (DAS & NAS)
- RAID arrays
- Massive scale-out data centers (MSO)
Compatibility:
This drive is compatible with any server that accepts 3.5in x 1.0in (LFF) SAS drives.
| Ultrastar® 7K6000 | |
|---|---|
| Model/Part No. | 0F22968 |
| Alt Model/Part No. | HUS726040ALS214 |
| Data Security Mode | N/A |
| Capacity | 4TB/4,000GB |
| Interface | SAS 12Gbps |
| Form Factor | 3.5-inch |
| Sector size (bytes) | 512n/512e: 512, 520, 528 |
| Performance | |
| Data buffer (MB) | 128 |
| Rotational speed (RPM) | 7200 |
| Latency average, (ms) | 4.16 |
| Interface transfer rate (MB/s, max) | 1200 |
| Sustained transfer rate (MB/s typical) (MiB/sec, typ) (MB/sec, typ) | 216/192 227/202 |
| Seek time (read, ms, typical) | 7.6/8.0 |
| Reliability | |
| Error rate (non-recoverable, bits read) | 1 in 10E15 |
| Load/Unload cycles (at 40°C) | 600,000 |
| MFBF (M hours) | 2.0 |
| Annualized Failure Rate (AFR) | 0.44% |
| Availability (hrs/day x days/wk) | 24x7 |
| Acoustics | |
| Idle (Bels, typical) | 2.9/3.6 |
| Power | |
| Requirement | +5 V, +12V |
| Operating (W, typical) | 11.0 |
| Idle (W) | 7.7 |
| Power consumption efficiency at idle (Watts/TB) (Watts/GB) | 1.3 0.0013 |
| Physical size | |
| z-height (mm) | 26.1 |
| Dimensions (width x depth, mm) | 101.6 (+/-0.25) x 147 |
| Weight (g/lb max) | 715/1.57631 |
| Environmental (Operating) | |
| Power-On Hours | 5º to 60º C |
| Shock (half-sine wave 2 ms, G) | 70 |
| Vibration (G RMS 5 to 500 Hz) | 0.67 (XYZ) |
| Environmental (Non-Operating) | |
| Ambient temperature | -40º to 70º C |
| Shock (half-sine wave, 1ms, G) | 300 |
| Random vibration (G RMS 5 to 500 Hz) | 1.04 (XYZ) |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: HUS726040ALS210 0F22941 0F22959 0F22968
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Refurbished
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
