Western Digital Ultrastar DC SN200 HUSMR7664BHP301 / 0TS1501 / 0TS1304 6.4TB HH-HL AIC MU MLC PCIe 3.0 x8 NVMe SSD

Western Digital Part #/MPN: HUSMR7664BHP301

DiscTech Item #: WDC-HUSMR7664BHP301-BN-OE

$1,999.00

Brand New
Condition Levels Explained
The product is brand new.
Warranty:1 Year DiscTech
Product Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
Low Stock:Call for ETA
Stock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

Back

$1,999.00

Enterprise Grade

Capacity: 6.4TB

Speed: Solid State

Interface Types: PCIe

Form Factor: HHHL (Half-Height/Half-Length)

Sector Size: 512 / 512e

Sustained Throughput: 6170/2200

Electrical Interface: PCIe - v3.0 - 16GBps

SSD Type: MLC

SSD Endurance DWPD: Enterprise Mixed Use / MU

Western Digital Ultrastar DC SN200 HUSMR7664BHP301 / 0TS1501 / 0TS1304 6.4TB / 6400GB HH-HL AIC Mixed Use MLC PCIe 3.0 x8 NVMe SSD - Brand New

Western Digital Ultrastar DC SN200 HUSMR7664BHP301 / 0TS1501 / 0TS1304 6.4TB / 6400GB HH-HL / Half Height-Half Length AIC / Add-in Card 126GBps Multi-Level Cell MU / Mixed Use PCI Express / PCIe 3.0 x8 NVMe 1.2 SSD / Solid State Disk Drive - Brand New

Ultrastar SN200 Series
PCIe SSDs for Application Acceleration
HGST extends its technology leadership with the introduction of the Ultrastar® SN200 Series solid-state drives (SSDs). The Ultrastar SN200 Series SSDs deliver a new level of performance and capacity for Enterprise, Cloud and Hyperscale environments. Enabling faster intelligence in the expanding digital demands of business applications the Ultrastar SN200 Series SSDs are a reliable resource for fast access to critical data. The HGST Ultrastar SN200 Series SSDs double the speed of the previous generation within the same power envelope. By offering exceptional 560,000 mixed read/write random 70/30 4KiB I/O performance on the 6.4TB HH-HL add-in card (AIC), the Ultrastar SN200 Series SSD will enable OLTP applications to scale to new levels.

Ultra-Low Latency and High Quality of Service (QoS)
To meet Tier 1 enterprise service level agreements (SLAs), data center managers need high QoS from their storage infrastructure. The HGST Ultrastar SN200 Series SSD delivers a 30% improvement over its predecessor providing consistent low latency as the device reaches its highest levels of throughput. The combination of high throughput performance and predictable low latency delivers extreme performance for today’s data intensive applications.

High Density Supports Data Growth
Delivering capacities up to 7.68TB in both form factors for 1 drive write per day (DW/D) and 6.4TB for 3 DW/D endurance ratings, the Ultrastar SN200 Series SSD delivers twice the density as its predecessor. In fact, at 7.68TB this product family delivers the highest density in both 2.5-inch SFF and HH-HL add-in card (AIC) form factors amongst NVMe-compliant devices at the time of its market introduction, providing swift access to even more data.

HGST Enterprise Storage Experience in Dual Port
HGST leverages decades of enterprise storage design expertise in high performance and high reliability to deliver its first dual-port NVMe PCIe SSD 2.5-inch drive. The dual-port feature supports two redundant paths to an SSD, ensuring access to data in the event of a failure in the data path. The dual-port option is available in all models of the Ultrastar SN200 SSD 2.5-inch SFF drive.

HGST Quality and Reliability
HGST Ultrastar SN200 Series SSD family extends the company’s long-standing tradition of performance and reliability leadership. A balanced combination of new and proven technologies enables high reliability and availability to customer data. HGST Ultrastar drives are backed by a 5-year limited warranty and an array of technical support and services, which may include customer and integration assistance. HGST is dedicated to providing a complete portfolio of SSD/HDD solutions to satisfy today’s monumental computing needs

Highlights

High-performance PCIe Gen 3 & NVMe™ 1.2 compliant
Storage capacity up to 7.68TB in both 2.5-inch SFF and HH-HL add-in card (AIC) form factors
Ultra-low consistent latency
Dual port (2x2) support for 2.5-inch drives for highly available system designs
Superior enterprise-grade reliability: Flash-aware RAID, end-to-end data path protection, advanced ECC, secure erase, PowerSafe™ power-loss protection

Applications & Workloads

Highest performance tier enterprise storage
Databases supporting mission critical applications
Cloud and Hyperscale computing
Online Transaction Processing (OLTP) and Online Analytical Processing (OLAP)
High Frequency Trading (HFT)
Virtualization

Compatibility:

This drive is compatible with any Server or PC that accepts Half-Height/Half-Length PCIe drives.

Western Digital Ultrastar SN260
Model Number	0TS1501 / 0TS1304
Alt Model Number	HUSMR7664BHP301
Capacity	6.4TB / 6400GB
Configuration
Interface	PCIe 3.0 x8 NVMe 1.2
Form Factor	HH-HL add-in card
Endurance (Drive writes per day)	3
Flash Memory Technology	15nm MLC NAND
Performance
Sequential Read (max MB/s, 128KiB)	6,170
Sequential Write (max MB/s, 128KiB)	2,200
Random Read (max IOPS, 4KiB)	1,200,000
Random Write (max IOPS, 4KiB)	200,000
Mixed Random Read/Write (max IOPS 70%R/30%W, 4KiB)	580,000
Write Latency 512B (μs)	20
Reliability
Error Rate in bits read	<1 in 10^17
MTBF	2M hours
Annual failure rate (AFR)	0.44%
Data Retention	3-month at 40°C
Power
Requirement (DC +/- 5%)	3.3V (aux) & 12V
Operating (W, typical)	25
Idle (W)	9
Physical size
z-height (mm)	14.49
Dimensions (width x depth, mm)	167.65 x 68.9
Weight (g, max.)	230 / 229
Environmental (non-operating)
Temperature	0°C to 55°C (Ambient)
Non-operating Temperature	-40° to 85°C
