Hitachi / EMC 0B31568 600GB 12Gb/s SAS Hard Drive
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 600GB |
| Speed: | 15K RPM |
| Interface Types: | SAS |
| Form Factor: | 2.5" SFF Server Drive |
| Electrical Interface: | SAS-3 12Gbps |
| RAM: | 128MB |
Description
Hitachi 0B31568 / HUC156060CSS200 / 118000394-02 600GB 2.5" 12Gbps 15K RPM Ultrastar C15K600 Enterprise SAS HDD - New Pull EMC OEM
Hitachi 0B31568 / HUC156060CSS200 / 118000394-02 600GB 2.5" 12Gbps 15K RPM Ultrastar C15K600 Enterprise SAS HDD - New Pull EMC OEM
EMC PT# 118000394-02 / 005050927
Compatibility
This drive is compatible with EMC VNX Series
VNXe3100
VNXe3150
Specifications
| Ultrastar C15K600 | ||
|---|---|---|
| Model Number | 0B31568 | |
| Alt Model Number | HUC156060CSS200 | |
| Configuration | ||
| Interface | SAS 12Gb/s | |
| Capacity (GB) | 600GB | |
| Sector size (variable, bytes/sector) | 512-Byte (512n) | |
| Recording zones | 40 | |
| Data heads (physical) | 6 | |
| Data disks | 3 | |
| Max. Areal density (Gbits/sq. in) | 528 | |
| Performance | ||
| Data buffer (MB) | 128 | |
| Rotational speed (RPM) | 15,030 | |
| Latency average (ms) | <2.0 | |
| Interface transfer rate (MB/s, max) | 1200 | |
| Sustained transfer rate (MB/s, typical) | 175 to 250 | |
| Seek time (read, ms, typical) | 2.9/3.1 | |
| Reliability | ||
| Error rate (non-recoverable, bits read) | 10 in 10e17 | |
| MTBF (M hours) | 2.0 | |
| Availability (hrs/day x day/wk) | 24x7 | |
| Acoustics | ||
| Idle (Bels, typical) | 3.2 | |
| Power | ||
| Requirement | +5 VDC (+/-5%), +12 VDC (+/-5%) | |
| Operating (W, typical) | 7.5 | |
| Idle (W) | 5.8 | |
| Idle efficiency (Watt/GB) | 0.0096 | |
| Physical size | ||
| z-height (mm) | 14.8 | |
| Dimensions (width x depth, mm) | 70.1 x 100.45 | |
| Weight (, max) | 219 | |
| Environmental (operating) | ||
| Ambient temperature | 5° to 55° C | |
| Shock (half-sine wave, 2ms, read operation) | 60G | |
| Vibration, random, no errors (G RMS 5 to 500 Hz) | 0.4, all axes | |
| Environmental (non-operating) | ||
| Ambient temperature | -40° to 70° C | |
| Shock (half-sine wave, 2ms) | >300G | |
| Vibration (RMS 5 to 500 Hz) | 1.5, all axes | |
Click here to view the manufacturer's item description/brochure
Alternate MPNs: HUC156060CSS200 005050927 118000394-02
Weight: 0.5 lb
Warranty: 1 Year DiscTech
Condition
The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.
Warranty
1 Year DiscTech Warranty
