Hitachi Ultrastar 0B24530 / HUS156030VLS600 Serial Attached SAS Hard Drives
- Special Order - Ships in 5-10 business daysSpecial Order - Ships in 5-10 business days
This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 300GB |
| Speed: | 15K RPM |
| Interface Types: | SAS |
| Form Factor: | 3.5" LFF Hard Drive |
| Electrical Interface: | SAS-2 6Gbps |
| RAM: | 64MB |
Description
Hitachi Ultrastar 15K600 0B24530 HUS156030VLS600 300GB 15K 6Gbps 64MB Cache Serial Attached SCSI Hard Drive AMS2500 - Refurbished
The Ultrastar 15K600 combines ultimate performance with high capacity in a single drive, storing up to 600GB of data while spinning at 15,000 RPM. The 64MB cache buffer is the largest in the industry in its class. The 6Gb/s Serial Attached SCSI (SAS) and 4Gb/s Fibre Channel Arbitrated Loop (FCAL) interfaces support the reliability required in the most demanding enterprise computing environments like on-line transaction processing, intensive data analysis, multi-user applications and data warehousing.
Highlights- 600GB capacity will store most everything
- Spinning at 15,000 RPM for mission-critical performance
- FCAL & SAS interfaces for reliable data throughput
- Advanced Power Management optimizes power consumption
- 64MB cache buffer – largest in the industry
- Self-encrypting models conform to TCG's Enterprise specification Applications / Environments
- Business & online transaction processing
- Internet, file sharing and email
- Decision support & RAID
- NAS, SAN and enterprise-class servers
- High performance computing and other applications requiring 24x7 availability
ALT PN: HUS156030VLS600 / DPN:0X150K X150K
Compatibility
Hitachi AMS2500 Hard Drive
Specifications
| Interface | 6Gb/s SAS / 4Gb/s FCAL |
| Capacity (GB) | 300 |
| Data Heads (physical) | 4 |
| PERFORMANCE | |
| Data buffer (MB) | 64 |
| Rotational Speed (RPM) | 15000 |
| Latency Average (ms) | 2 |
| Interface transfer rate (MB/sec, max) | 600 / 400 |
| Sustained transfer rate (MB/sec, typ.) | 198 to 119 |
| Seek Time (read, ms, typical) | 3.4 |
| Reliability | |
| Error Rate (non-recoverable, bits read) | 1 in 10^16 |
| MTBF (M hours) | 1.6 |
| Availability (hrs/day x days/wk) | 24x7 |
| Acoustics | |
| Idle (Bels) | 3.7 |
| Power | |
| Requirement | +5 VDC (+/5%) +12 VDC (+/5%) |
| Operating (W, typical) | 13.2 |
| Unload idle (W) | 7.7 |
| Physical size | |
| Z-height (mm) | 25.8 |
| Dimensions (width x depth, mm) | 101.6 x 146.2 |
| Weight (g, max) | 750 |
| Environmental (operating) | |
| Ambient temperature | 5º to 55ºC |
| Shock (half-sine wave) | 30G (2ms) |
| Vibration | 1.5Gm all axes |
| Environmental (non-operating) | |
| Ambient temperature | -40º to 70ºC |
| Shock (half-sine wave) | 250G (2ms) |
| Vibration | 2.0G, all axes |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: HUS156030VLS600
Weight: 1 lb
Warranty: 1 Year DiscTech
Condition
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
Warranty
1 Year DiscTech Warranty
