HGST Part #/MPN: 0F27486
DiscTech Item #: HIT-0F27486-BN-OE-DEL
- Brand New
- Warranty:1 Year DiscTech
- Special Order - Call for Lead Time
Enterprise Grade
Capacity: 10TB
Speed: 7.2K RPM
Interface Types: SATA
Form Factor: 3.5" LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 237 / 215
Average Seek Time: 8.0 / 8.6
Electrical Interface: SATA 600 - 6Gbps
On-Board Cache: 256MB
Dell RVFR2 / HGST Hitachi Ultrastar He10 0F27486 / HUH721010ALE600 10TB 6Gbps 7.2K Enterprise ISE SATA Hard Drive - Brand New OEM
HGST Hitachi Ultrastar He10 0F27486 / HUH721010ALE600 10TB 6Gbps 7.2K Enterprise ISE SATA HDD Dell Enterprise Class RVFR2 / 0RVFR2 - Brand New OEM
Hitachi Ultrastar He10 3.5" Helium Platform Enterprise Hard Drive Highlights
• 10TB capacity in a standard 3.5-inch form factor
• PMR technology works with all capacity enterprise applications & environments
• Reliable, field-proven, 3rd generation design
• Superior power efficiency (Watts/TB)
• Compared to 8TB air drives
—25% more capacity
—47% more power efficient (Watts/TB)
—25% more reliable
• SATA 6Gb/s and SAS 12Gb/s Models
—12Gb/s SAS compatible with next gen data centers; backwards compatible with 6Gb/s SAS
• Instant Secure Erase (ISE) & Self-Encrypting Drive (SED) options Applications/Environments
• Enterprise and data center applications where capacity density and power efficiency are paramount
• Cloud & Hyperscale storage
• Massive scale-out high-density data centers (MSO)
• Bulk storage using object storage solutions like Ceph™ and Hadoop® to support Big Data Analytics
• Centralized video surveillance
• Drop-in ready for all mainstream enterprise capacity applications
Dell DPN#: RVFR2 / 0RVFR2
Compatibility:
This drive is compatible with any server that accepts large capacity 3.5in x 1.0in (LFF) SATA drives.
| HGST Ultrastar He10 | |
|---|---|
| Model/Part No. | 0F27486 |
| Alt Model/Part No. | HUH721010ALE600 |
| Capacity | 10TB/10,000GB |
| Configuration | |
| Interface | SATA 6Gb/s |
| Format : Sector size (bytes) | 512e: 512-Byte 4Kn: 4096 |
| Max. Areal density (Gbits/sq. in) | 816 |
| Performance | |
| Data buffer (MB) | 256 |
| Rotational speed (RPM) | 7200 |
| Latency average (ms) | 4.16 |
| Interface transfer rate (MB/s, max) | 600 |
| Sustained transfer rate (MB/s, typ.) | 237 (read), 215 (write) |
| Seek time (read, ms, typical) | 8.0 / 8.6 |
| Reliability | |
| Error rate (non-recoverable, bits read) | 1 in 10E15 |
| Load/Unload cycles (at 40°C) | 600,000 |
| Availability (hrs/day x days/wk) | 24x7 |
| MTBF (M hours) | 2.5 |
| Acoustics | |
| Idle (Bels, typical) | 2.0 |
| Power | |
| Requirement | +5 VDC (+/-5%) +12 VDC (+/-5%) |
| Operating (W, typical) | 6.8 |
| Idle (W) | 5.0 |
| Power consumption efficiency at idle (W/TB) (W/GB) | 0.51 0.00050 |
| Physical size | |
| z-height (mm) | 26.1 |
| Dimensions (width x depth, mm) | 101.6 (+/- 0.25) x 147 |
| Weight (g, max) | 660 |
| Environmental (Operating) | |
| Ambient temperature | 5°C to 60°C |
| Shock (half-sine wave, read operation, G) | 70 (2ms) |
| Vibration (G RMS 5 to 500 Hz) | 0.67, all axes |
| Environmental (Non-Operating) | |
| Ambient temperature | -40°C to 70°C |
| Shock (half-sine wave, G) | 300 (1ms)/ 150 (11ms) |
| Random Vibration (G RMS 2 to 200 Hz) | 1.04, all axes |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: HUH721010ALE600 RVFR2 0RVFR2
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Brand New
1 Year DiscTech Warranty
