1TB / 1000GB SAS Seagate Constellation ST91000640SS / IBM 00WY967 Serial SCSI / SAS 2.5" SFF Hard Disk Drive
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 1TB |
| Speed: | 7.2K RPM |
| Interface Types: | SAS |
| Form Factor: | 2.5" SFF Server Drive |
| Electrical Interface: | SAS-2 6Gbps |
| RAM: | 64MB |
Description
IBM 00WY967 / Seagate Constellation.2 ST91000640SS 1TB / 1000GB 7.2K 6.0Gbps 2.5" SFF Serial SCSI / SAS Hard Drive - Refurbished
Overview
Seagate® Constellation.2™ drives are the most energy efficient enterprise drives on the market. Designed for enterprise robustness, Constellation.2 is available in capacities up to 1TB and offers reliable storage for high capacity servers and storage arrays in a minimal footprint.
Key Features and Benefits
* Industry’s first 2.5-inch 1TB capacity-optimized drive for dense, space-constrained data centers allows you to store twice as much data in the same footprint.
* Build highly efficient bulk storage solutions while lowering your power consumption costs
* Designed for robust 24x7 operation with a 1.4M hour mean-time-between-failure (MTBF) rating
* Best-in-class rotational vibration tolerance ensures unrivaled performance in high spindle-density applications, and multi-drive firmware maximizes system availability
* Choose from 6Gb/s SAS with improved data integrity, scalability and fastest data access or SATA 6Gb/s for economical 7200-RPM performance
* TCG- compliant, Self-Encrypting Drive (SED) security option cuts IT drive retirement expenses while securely protecting data*
IBM 00WY967
Compatibility
This drive is compatible with any of our SAS drive trays and any of our SAS controllers.
Specifications
| Drive specification | IBM: 00WY967 |
| Formatted Gbytes (512 bytes/sector) | 1000 |
| Bytes per sector | 512 |
| Spindle speed (RPM) | 7,200 |
| I/O data transfer rate (MBps) | 600 |
| Cache buffer | 64 MB |
| Interface Type | 6.0Gbps SAS |
| Seek time (read / write) ms | 7.5 / 8.5 |
| Sustainted Data Transfer Rate | 115MB/s |
| Dimensions (HxLxW) mm | 15 / 100.45 / 70.1 |
| Weight | 0.200 kg |
| Operating Shock (Read) | 25G, 2ms |
| Non-operating Shock | 400G, 2ms |
| Temperature - Operating | 5C -60C |
| Temperature - Non-operating | -40C - 70C |
| Current Requirements 12VDC (Read/Write, Idle) | 10.8w / 8.0w |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: ST91000640SS
Weight: 0.5 lb
Warranty: 1 Year DiscTech
Condition
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
Warranty
1 Year DiscTech Warranty
