IBM / NVIDIA 43V5921 Quadro 6000 6GB GPU Graphics Card

IBM Part #/MPN: 43V5921

DiscTech Item #: IBM-43V5921-NP-OE

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.


Interface Types: PCIe

Resolution: 2560x1600

IBM / NVIDIA 43V5921 Quadro 6000 6GB GDDR5 PCIe 384-bit GPU Graphics Card - New Pull

IBM / NVIDIA 43V5921 Quadro 6000 6GB GDDR5 PCIe / PCI Express 384-bit GPU / Graphics Processing Unit Graphics Card - New Pull

Quadro 6000
The NVIDIA® Quadro® 6000 professional graphics solution is a technological breakthrough, delivering up to 5x times faster performance across a broad range of professional applications. Featuring new Scalable Geometry Engine™ technology, Quadro 6000 can deliver an unheard of 1.3 billion triangles per second, shattering previous 3D graphics limitations.

Accelerate your entire workflow
The NVIDIA® Quadro® 6000 professional graphics solution is a true technological breakthrough, delivering up to 5x faster performance across a broad range of design, animation and video applications. Built on the innovative NVIDIA Fermi architecture, the Quadro 6000 is the first professional-class GPU to integrate high performance computing capabilities with advanced visualization techniques, transforming modern workflows.

Featuring new Scalable Geometry Engine™ technology, Quadro can deliver an unheard of 1.3 billion triangles per second, shattering previous 3D graphics limitations². With Quadro solutions, your work flows -- you can design, iterate and deliver higher quality projects in less time.

The revolutionary Quadro GPU architecture
Modern applications harness the latest NVIDIA® CUDA™ parallel processing architecture of the Quadro 6000 solution to deliver performance gains up to 8x faster when running computationally intensive applications such as ray tracing, video processing and computational fluid dynamics. For high-precision, data-sensitive applications, Quadro 6000 is the only professional graphics solution with ECC memory and fast double precision capabilities to ensure the accuracy and fidelity of your results. From medical imaging to structural analysis applications, data integrity and precision is assured, without sacrificing performance.

Visual Supercomputing Platform
Quadro 6000 is not only a graphics processor; it drives an entire visual supercomputing platform, incorporating hardware and software that enables advanced capabilities such as stereoscopic 3D, scalable visualization and 3D high-definition broadcasting.

Supercharged professional applications
NVIDIA professional software technologies, from CUDA software to application acceleration engines, combined with Quadro, accelerate applications from companies such as Adobe, Autodesk, RTT, Dassault Systemes, Bunkspeed and many more.


GPU Features

  • Next-Generation NVIDIA® CUDA™ Architecture - Breakthrough NVIDIA CUDA parallel computing architecture, code named Fermi, tightly integrates advanced visualization and compute features delivering performance that greatly accelerates professional workflows.
  • NVIDIA® Scalable Geometry Engine - Dramatically improves geometry performance across a broad range of CAD, DCC and medical applications, enabling you to work interactively with models and scenes that are an order of magnitude more complex than ever before.
  • Fast 64-Bit Floating Point Precision - Industry’s fastest double precision floating point performance enabling accurate results on mission-critical applications, including computer-aided-design, finite element analysis to computational fluid dynamics.
  • Framebuffers up to 6 GB¹ of GDDR5 Memory with Ultra-Fast Bandwidth - Industry’s first GPU with 6 GB¹ of memory and memory bandwidth of 144 GB/sec for display of large models and complex scenes, as well as computation of massive datasets.
  • Error Correcting Code (ECC) Memory - Meets strict requirements for mission critical applications with uncompromised computing accuracy and reliability for workstations. Offers protection of data in memory to enhance application data integrity.
  • NVIDIA® Parallel DataCache - Supports a true cache hierarchy combined with on-chip shared memory. L1 and L2 caches drive exceptional throughput, accelerating features such as real-time ray tracing, physics and texture filtering.
  • NVIDIA GigaThread™ Engine - Provides up to 10x faster context switching compared to previous generation architectures, concurrent kernel execution, and improved thread block scheduling.
  • Dual Copy Engines - Enables the highest rates of parallel data processing and concurrent throughput between the GPU and host, accelerating techniques such as ray tracing, color grading and physical simulation.
  • Fast 3D Texture Transfer - Fast transfer and manipulation of 3D textures resulting in more interactive visualization of large volumetric datasets.
  • Hardware 3D Window Clipping - Hardware accelerated clip regions (data transfer mechanism between a window and the frame buffer) improve overall graphics performance by increasing transfer speed between color buffer and frame buffer.
  • Unified Driver Architecture (UDA) - The NVIDIA UDA guarantees forward and backward compatibility with software drivers. Simplifies upgrading to a new solution because all Quadro products work with the same driver software.

Image Quality

  • Full-Scene Antialiasing (FSAA) - Up to 64x FSAA (128x with SLI) dramatically reduces visual aliasing artifacts or “jaggies,” resulting in unparalleled image quality and highly realistic scenes.
  • GPU Tessellation with Shader Model 5.0 - Quadro Tessellation Engines automatically generate finely detailed geometry, for cinematic quality environments and scenes, without sacrificing performance.
  • 16K Texture and Render Processing - The ability to texture from and render to 16K x 16K surfaces. Beneficial for applications that demand the highest resolution and quality image processing.
  • NVIDIA High Precision High Dynamic Range (HDR) Technology - Sets new standards for image clarity and quality through floating point capabilities in shading, filtering, texturing, and blending. Enables unprecedented rendered image quality for visual effects processing.

Display Features

  • High-Quality Display Connectors - Attaches to ultra-high-resolution panels producing phenomenal photorealistic image quality from a range of display connectors. Through the GPU support for two active connectors including, dual-link DVI-I with up to 3840 x 2400 @ 24Hz, DisplayPort with up to up to 2560 x 1600 @ 60Hz, or HDMI from a cable.
  • 30-Bit Color Fidelity - 30-bit color fidelity (10-bits per color) enables billions rather than millions of color variations for rich, vivid image quality with the broadest dynamic range.
  • NVIDIA® Quadro® Digital Video Pipeline - Quadro Digital Video Pipeline is the industry’s only GPU-accelerated solution for real-time acquisition, processing, and delivery of high-resolution SDI video, across traditional and now 3D video broadcast environments. Supports uncompressed 8-, 10-, 12-bit SDI via optional Quadro SDI Capture and Quadro SDI Output cards.
  • NVIDIA® Quadro® G-Sync Solution - The Quadro G-Sync option card is an advanced solution that ensures frame synchronization between GPUs and provides a way to synchronize to an external source (also known as house sync). G-Sync allows advanced visualization systems to utilize many projectors or displays in unison delivering unprecedented levels of realism and betters ways to collaborate.
  • NVIDIA® 3D Vision Pro™ - 3D Vision Pro includes advanced active shutter glasses delivering crystal-clear stereoscopic 3D visualization for the most immersive experience. RF technology enables a range of environments ranging from collaborative work spaces to theaters. 3D Vision Pro solution sold separately.
  • OpenGL Quad Buffered Stereo Support - OpenGL Quad Buffered Stereo offers professional applications the capability of smooth and immersive 3D Stereo experience.
  • OpenGL Quad Buffered Stereo Support - OpenGL Quad Buffered Stereo offers professional applications the capability of smooth and immersive 3D Stereo experience.
  • Professional 3D Stereo Synchronization - Enables robust control of stereo effect through a dedicated 3-pin mini-din connection between the graphics card and 3D stereo hardware.

Software Support

  • Programming the CUDA Parallel Computing Architecture - General purpose GPU computing using standard programming languages like C/C++ and Fortran, and emerging APIs such as OpenCL and Direct Compute. This broad adoption of CUDA is accelerating techniques like ray tracing, video and image processing, and computation fluid dynamics.
  • Cg Programming - Programmable GPU leverages Cg high-level, open-standard shading language to enable the creation and integration of real-time photorealistic effects into 3D models, scenes and designs.
  • Microsoft® Windows® 7 Support - Take advantage of all the new and compelling features included with Windows 7, delivering unprecedented application performance, advanced visual realism, and premium reliability with superior application compatibility on mobile and desktop workstations.
  • Shader Model 5.0 Programmability - Infinite length vertex programs and dynamic flow control remove the previous limits on OpenGL and DirectX shader programs, delivering sophisticated effects never before imagined.
  • NVIDIA Graphics API Extensions - NVIDIA provides a set of extensions to standard graphics APIs for Linux and Windows, enabling applications to take maximum advantage of state-of-the-art GPU capabilities.
  • NVIDIA Application Acceleration Engines Support - Supercharge application performance and capabilities with highly optimized software modules, including SceniX™, OptiX™, and CompleX™, for advanced creative and investigative possibilities.
  • NVIDIA® SLI® Technology - NVIDIA SLI technology leverages multiple GPUs to dynamically scale graphics performance, enhance image quality, expand display real estate and assemble a fully virtualized system. Available on Quadro SLI certified platforms only.
  • NVIDIA® Multi-OS - NVIDIA Multi OS allows a user to run multiple Windows or Linux workstation applications from a single system, with each Operating System directly assigned to a Quadro graphics solution. Only available on NVIDIA Multi-OS certified platforms.
  • NVIDIA® SLI® Mosaic Technology - NVIDIA SLI Mosaic Technology enables transparent scaling of any application, tear-free across up to four display channels, including support for 4K projection, while delivering full performance from a single SLI certified workstation. Available on Quadro SLI certified platforms only.

Industry Standard

  • Compatible with Industry Standard Architectures - Compatible with Microsoft and Linux operating systems, as well as Intel and AMD x86 32- and 64-bit microprocessor architectures.
  • Ultra-Quiet Design - Acoustics lower than 28db for an ultra-quiet desktop environment.


System x3650 M4 BDSystem x3500 M4System x3650 M4

NVIDIA Quadro 6000 Specification
Model Number43V5921
Alt Model Number900-51030-0452-000
NVIDIA Quadro GPUQuadro 6000
CUDA Cores448
Form Factor4.376" H x 9.75" L
Dual Slot
Gigaflops (Single Precision)1030.4
Gigaflops (Double Precision)515.2
GPU Memory
Total Frame Buffer6 GB
Memory Interface384-bit
Memory Bandwidth (GB/sec)144 GB/s
Display Support
Dual Link DVI-I1
Display Port2
Number of Digital Outputs2
Number of Analog Outputs1
Stereo (3-pin Mini-DIN)Yes
Maximum Display Resolution Digital @ 60Hz2560x1600
Active Display Channels2
3D Vision/3D Vision ProYes
Feature Support
Shader Model5.0
Microsoft DirectX11
NVIDIA Multi-OS TechnologyYes
SLI Mosaic TechnologyYes
NVIDIA CUDA ArchitectureYes
SDI OptionYes
G-Sync OptionYes
SLI Frame Rendering SupportYes
NVIEW Display ManagementSoftwareYes
FSAA (maximum)64x (128x with SLI)
Number of Slots2
Audio Support (via DisplayPort)Yes
Thermal and Power
EnergyStar EnablingYes
Maximum Power Consumption204 W
Auxiliary Power Cable(s) RequiredSingle 8-pin OR dual 6-pin

Click here to view the manufacturer's item description/brochure

Alternate MPNs: 900-51030-0452-000 00D4484

Weight: 3 lb

Warranty: 1 Year DiscTech

New Pull

Condition Levels Explained

The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
