Intel 520 Series SSDSC2CW480A310 480GB 2.5" MLC SSD SATA3 Hard Drive


DiscTech Item #: INT-SSDSC2CW480A310-BN-5Y

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.


Capacity: 480GB

Speed: Solid State Memory

Interface Types: SATA

Form Factor: 2.5inx9mm Fits Most laptops

Sector Size: 512 / 512e

Electrical Interface: SATA 600 - 6.0Gbps


SSD Endurance DWPD: Consumer / Value

Intel 520 Series SSDSC2CW480A310 / SSDSC2CW480A3 480GB 2.5" MLC SSD SATA3 Hard Drive - Brand New

Intel 520 Series SSDSC2CW480A310 480GB 2.5" MLC SSD SATA3 Hard Drive - Brand New

Intel Model Number: SSDSC2CW480A3
Alt. Ordering Part Number: SSDSC2CW480A301

Intel Solid-State Drives (Intel SSDs) continue to evolve with the Intel SSD 500 Family. Available in a wide range of capacities up to 480 GB, the Intel Solid-State Drive 520 Series delivers leading performance for Serial Advanced Technology Attachment (SATA)-based computers. By combining Intel's leading 25nm NAND flash memory technology with SATA 6Gb/s interface support, the Intel SSD 520 Series delivers sequential read speeds of up to 550 MB/s and sequential write speeds of up to 520 MB/s. The industry-standard 2.5-inch form factor enables interchangeability with existing hard disk drives (HDDs) and native SATA HDD drop-in replacement with the enhanced performance, reliability, and ruggedness offered by an SSD.

The Intel SSD 520 Series also offers built-in data protection features including Advanced Encryption Standard (AES) 256-bit Encryption, End-to-End Data Protection, and Data Compression. Now that your work is safe, use the world-class performance of the Intel SSD 520 Series to dominate your gaming competition or to reach new levels of creativity and productivity.


This SATA SSD hard drive is compatible with all systems that support 2.5" SATA drives.

Intel Model NumberSSDSC2CW480A3
Ordering Part NumbersSSDSC2CW480A310
Model Name520 Series
Formatted Capacity480 Gbytes
Components Intel NAND Flash MLC
Form Factor 2.5"
External (I/O) Transfer Rate (max)SATA III 6.0 Gb/s
Max Seq. Read 550MB/s
Max Seq. Write 520 MB/s
4KB Random Read/WriteUp to 50,000 IOPS / 42,000 IOPS
Latency - Read80 µs
Latency - Write85 µs
MTBF 1,200,000 Hours
Uncorrectable Bit Error Rate 1 sector per 10 x16th
Operating Temp. 0C - +70C

Click here to view the manufacturer's item description/brochure

Alternate MPNs: SSDSC2CW480A3 SSDSC2CW480A301

Weight: 0.5 lb

Warranty: 5 Year Manufacturer

Brand New

Condition Levels Explained

The product is brand new.

5 Year Manufacturer Warranty

Product Warranties Explained

The product has a manufacturer warranty for the time period specified.
