INTEL Part #/MPN: SSDSC2BB012T6R
DiscTech Item #: INT-SSDSC2BB012T6R-NP-OE-DEL
- New PullCondition Levels Explained
The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Capacity: 1.2TB
Speed: Solid State
Interface Types: SATA
Form Factor: 2.5" x 7mm Fits All laptops
Encryption/SED Supported
Sector Size: 512 / 512e
Sustained Throughput: 500 / 440
Electrical Interface: SATA 600 - 6Gbps
SSD Type: MLC
SSD Endurance DWPD: Consumer / Value
Intel DC S3510 Series SSDSC2BB012T6R / KYTDG 1.2TB 6Gbps 2.5" MLC SATA SSD - New Pull OEM
DPN 0KYTDG / KYTDG
The Intel® Solid State Drive Data Center Family for SATA expands with the Intel® SSD DC S3510 Series. The Intel SSD DC S3510 Series offers the next generation of data center SSDs optimized for mixed read-write performance, endurance, and strong data protection.
The Intel SSD DC S3510 Series accelerates data center performance with read/write throughput speeds up to 500/430 megabytes per second (MB/s) and 4K random read/write input/output operations per second (IOPs) up to 65,000/15,200. Applications benefit from 55 μs typical latency with max read latencies2 of 500 μs 99.9 percent3 of the time. Combining performance with low typical active power (less than 6.8 watts1 4) the Intel SSD DC S3510 Series improves data center efficiency with superior quality of service and reduced energy costs.
Compatibility:
This drive is compatible with any server or laptop that accepts 2.5"x7mm SATA drives.
| Specifications | |
|---|---|
| Capacity | 1200 GB |
| Addressable Data Blocks 512K | 2,344,225,968 |
| Form Factor | 2.5" 7mm |
| Interface | SATA 3.0 6Gb/S |
| Lithography Type | 16 nm |
| Sequential - Read - Write | - 500MB/s - 440MB/s |
| Random - Read - Write | - 67000 IOPS - 20000 IOPS |
| Latency - Read - Write | - 55 µs - 66 µs |
| Power - Active - Idle | - 6.8 W - 0.6 W |
| Weight | 94 grams +-2 grams |
| Mean Time Between Failures (MTBF) | 2000000 |
| Uncorrectable Bit Error Rate (UBER) | 1 sector per 10^17 bits read |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 0KYTDG KYTDG
Weight: 0.5 lb
Warranty: 1 Year DiscTech
New Pull
The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
