Dell N8PW5 Intel E810-CQDA2 OCP 3.0 Ethernet Network Adapter NIC Quad Port PCIe 4.0 x16 100 Gigabit 100/50/25/10GbE SFP28 x 2 - Brand New
| Interface Types: | OCP 3.0 |
| Electrical Interface: | Ethernet 100 Gigabit 100GbE 100Gbps |
Description
Dell N8PW5 Intel E810-CQDA2 OCP 3.0 Ethernet Network Adapter NIC Quad Port PCIe 4.0 x16 100 Gigabit 100/50/25/10GbE SFP28 x 2 - Brand New
Dell N8PW5 Intel E810-CQDA2 Ethernet Network Adapter NIC Quad Port PCIe 4.0 x16 100 Gigabit 100/50/25/10GbE SFP28 x 2 - Brand New
Key Features
- Single and Dual-Port QSFP28
- Application Device Queues (ADQ)
- OCP 3.0 Connector Standard
- PCI Express (PCIe) 4.0 x16
- Dynamic Device Personalization (DDP)
- Ethernet Port Configuration Tool (EPCT)
- Supports both RDMA iWARP and RoCEv2
Efficient workload-optimized performance at Ethernet speeds of 10 to 100Gbps
Intel® Ethernet Network Adapter E810-CQDA1/CQDA2
Performance for Cloud Applications
Delivers the bandwidth and increased application throughput required for demanding cloud workloads including edge services, web servers, database applications, caching servers, and storage targets.
- Application Device Queues (ADQ) improves application response time predictability using advanced traffic-steering technology
- Dynamic Device Personalization (DDP) enhances packet classification capabilities, to deliver up to 3x throughput improvement¹ for some cloud workloads
- Supports both RDMA iWARP and RoCEv2 for high-speed, low-latency connectivity to storage targets
Optimizations for Communications Workloads
Provides packet classification and sorting optimizations for high-bandwidth network and communications workloads, including mobile core, 5G RAN, and network appliances.
- Dynamic Device Personalization (DDP) supports existing and new communications-specific protocols improving packet-processing efficiency up to 3x for some Network Functions Virtualization (NFV) workloads
- IEEE 1588 Precision Time Protocol (PTP) v2 enables precise clock synchronization across the 5G RAN deployments
- Enhanced Data Plane Development Kit (DPDK) support increases packet-processing speeds
Compatibility:
This adapter is compatible with any server having a OPC 3.0 slot and PCIe bus support.
Specifications
| Adapter Features | Details | ||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Data Rate Supported | 100/50/25/10GbE Per Port | ||||||||||||||||||||||||||||||||||||
| Bus Type/Bus Width | OCP 3.0 Connector Standard PCIe 4.0 x16 Interface | ||||||||||||||||||||||||||||||||||||
| Hardware Certifications | BSMI, CE, CMIM, FCC, ICES, KCC, RCM, UKCA, cURus, and VCCI | ||||||||||||||||||||||||||||||||||||
| BMSI RoHS and RoHS-compliant | Product is compliant with Taiwan Bureau of Standards, Metrology and Inspection (BMSI), and EU RoHS Directive 2 2011/65/EU (Directive 2011/65/EU) and its amendments (e.g. 2015/863/EU) | ||||||||||||||||||||||||||||||||||||
| Controller | Intel® Ethernet Controller E810-CAM1 (Single Port) Intel® Ethernet Controller E810-CAM2 (Dual Port) | ||||||||||||||||||||||||||||||||||||
| Bracket | Full-height bracket installed Low-profile bracket included in package | ||||||||||||||||||||||||||||||||||||
| Dimension | 167 mm x 69 mm | ||||||||||||||||||||||||||||||||||||
| Power Consumption |
|
Click here to view the manufacturer's item description/brochure
Alternate MPNs: N0W1X 0N0W1X 0N8PW5 N8PW5
Weight: 0.5 lb
Warranty: 1 Year DiscTech
Condition
Brand New
Warranty
1 Year DiscTech Warranty
