Dell P98F6 2TB U.2 PCIe Gen3 x4 NVMe MU 3-DWPD 2.5" SSD Solid State Drive | Intel DC P3600 SSDPE2ME020T4D

- In Stock:28Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 2TB |
| Speed: | Solid State |
| Interface Types: | PCIe |
| Form Factor: | 2.5" SFF Server Drive |
| SSD Endurance DWPD: | Enterprise Mixed Use / MU |
| Electrical Interface: | PCIe 3.0 16GBps |
Description
Dell P98F6 2TB U.2 PCIe Gen3 x4 NVMe MU 3-DWPD 2.5" SSD Solid State Drive | Intel DC P3600 SSDPE2ME020T4D - Certified 95
Dell P98F6 2TB /2000GB U.2 PCIe / PCI Express Gen3 x4 NVMe MU / Mixed Use 3-DWPD /3 Drive Write Per Day 2.5" SSD Solid State Drive | Intel DC P3600 SSDPE2ME020T4D - Certified 95
Intel Solid State Drive DC P3600 Series
P36 Series is a PCIe Gen3 SSD architected with the high performance controller interface – NVMe (Non-Volatile Memory Express) delivering leading performance, low latency and Quality of Service. Matching the performance with world –class reliability and endurance, P3600 Series offers a range of capacity – 400GB, 800GB, 1.2TB, 1.6TB and 2TB in both Add-in card and 2.5-inch form factor.
With PCIe Gen3 support and NVMe queuing interface, P3600 Series delivers excellent sequential read performance of up to 2.8GB/s and sequential writes speeds of up to 1700MB/s. P3600 Series delivers very high random read IOPS of 450K and random write IOPS of 70K fr 4KB operations. Taking advantage of the direct path from the storage to the CPU by means of NVMe, P3600 Series exhibits low latency of less than 20 µs for sequential access to the SSD.
P3600 Series includes these key features:
- Consistently High IOPS and throughput
- Sustained low latency
- Variable Sector Size and End-to-End data path protection
- Enhanced power-loss data protection
- Power loss protection capacitor self-test
- Out of band management
- Thermal throttling and monitoring
Model Number: SSDPE2ME020T4D
Dell Model Number: P98F6, 0P98F6
Compatibility
This drive is compatible with any server that accepts Half-Height/Half-Length PCIe drives.
Specifications
| DC P3600 Series | |
|---|---|
| Model Number | SSDPE2ME020T4D |
| Dell Model Number | P98F6 |
| ESSENTIALS | |
| PERFORMANCE | |
| RELIABILITY | |
| PACKAGE SPECIFICATIONS | |
| ADVANCED TECHNOLOGIES | |
| Capacities | 2TB / 2000GB |
| Sequential Read | Up to 2600 MB/s |
| Sustained Write | Upt to 1700 MB/s |
| Random Read (100% Span) | 450000 IOPS |
| Random Write (100% Span) | 56000 IOPS |
| Latency - Read | 20 µs |
| Latency - Write | 20 µs |
| Lifetime Endurance | 3 Drive Writes Per Day |
| Interface | NVMe PCIe 3.0x4 |
| Form Factor | 2.5 in. |
| Height | 15mm |
| Weight | 125g |
| Life Expectancy | 2 MTBF / 230 Years |
| Power Consumption (Active) | <25W (Write) / <11W (Read) |
| Power consumption (Idle) | 4W Typical |
| NAND Flash Memory | Intel NAND Flash Memory Multi-Level Cell (MLC) 20nm |
| Operating Temperature | 0°C to 35°C ambient / 0° to 70° Case |
| RoHS Compliance | Yes |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: P98F6 0P98F6
Weight: 1 lb
Warranty: 1 Year DiscTech
Condition
Certified 95
Warranty
1 Year DiscTech Warranty
