INTEL Part #/MPN: SSDPEDME020T4D
DiscTech Item #: INT-SSDPEDME020T4D-BN-OE-DEL
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Enterprise Grade
Capacity: 2TB
Speed: Solid State Memory
Interface Types: PCIe
Form Factor: Half-Height/Half-Length
Sector Size: 512 / 512e
Sustained Throughput: 2600/1700
Average Seek Time: 20 µs/20 µs
Electrical Interface: PCIe - v3.0 - 16GBps
SSD Type: MLC
SSD Endurance DWPD: Enterprise Mixed Use
Wattage/VA: 25W
Voltage: 3.3V
Intel DC P3600 SSDPEDME020T4D / SSDPEDME020T401 / JFRHP 2TB HHHL Mixed Use eMLC NVMe PCI Express / PCIe 3.0 NVMe SSD - Brand New OEM
Intel DC P3600 SSDPEDME020T4D / SSDPEDME020T401 / JFRHP 2TB / 2000GB Half Height, Half Length Mixed Use 15 Drive Writes Per Day Enterprise Multi-Level Cell eMLC Peripheral Component Interconnect Express 3.0 Non-Volatile Memory Express Solid State Disk Drive - Brand New OEM
Intel Solid State Drive DC P3600 Series
P36 Series is a PCIe Gen3 SSD architected with the new high performance controller interface – NVMe (Non-Volatile Memory Express) delivering leading performance, low latency and Quality of Service. Matching the performance with world –class reliability and endurance, P3600 Series offers a range of capacity – 400GB, 800GB, 1.2TB, 1.6TB and 2TB in both Add-in card and 2.5-inch form factor.
With PCIe Gen3 support and NVMe queuing interface, P3600 Series delivers excellent sequential read performance of up to 2.8GB/s and sequential writes speeds of up to 1700MB/s. P3600 Series delivers very high random read IOPS of 450K and random write IOPS of 70K fr 4KB operations. Taking advantage of the direct path from the storage to the CPU by means of NVMe, P3600 Series exhibits low latency of less than 20 µs for sequential access to the SSD.
P3600 Series includes these key features:
- Consistently High IOPS and throughput
- Sustained low latency
- Variable Sector Size and End-to-End data path protection
- Enhanced power-loss data protection
- Power loss protection capacitor self-test
- Out of band management
- Thermal throttling and monitoring
Alt Model Number: SSDPEDME020T401, SSDPEDME020T410 (10pk)
Dell Model Number: JFRHP, 0JFRHP
Compatibility:
This drive is compatible with any server that accepts Half-Height/Half-Length PCIe drives.
DC P3600 Series | |
---|---|
Model Number | SSDPEDME020T4D |
Alt Model Number | SSDPEDME020T401, SSDPEDME020T410 (10pk) |
Dell Model Number | JFRHP |
ESSENTIALS | |
Capacities | 2TB / 2000GB |
Status | Launched |
Launch Date | Q2'14 |
Lithography Type | 20nm |
PERFORMANCE | |
Sequential Read (up to) | 2600MB/s |
Sequential Write (up to) | 1700 MB/s |
Random Read (100% Span) | 450000 IOPS |
Random Write (100% Span) | 56000 IOPS |
Latency - Read | 20 µs |
Latency - Write | 20 µs |
Power - Active | 25W (write), 10W (read) |
Power - Idle | 4W |
RELIABILITY | |
Vibration - Operating | 2.17 GRMS |
Vibration - Non-Operating | 3.13 GRMS |
Shock (Operating and Non-Operating) | 50 G Trapezoidal, 170 in/s |
Operating Temperature Range | 0°C to 55°C |
Endurance Rating (Lifetime Writes) | 10.95 PBW (JEDEC workload) |
Mean Time Between Failures (MTBF) | 2,000,000 Hrs |
Uncorrectable Bit Error Rate (UBER) | less than 1 sector per 1e17 bits read |
PACKAGE SPECIFICATIONS | |
Weight | 195gm |
Form Factor | HHHL (CEM2.0) |
Interface | PCIe NVMe 3.0 x4 |
ADVANCED TECHNOLOGIES | |
Enhanced Power Loss Data Protection | Yes |
High Endurance Technology (HET) | Yes |
Temperature Monitoring and Logging | Yes |
End-to-End Data Protection | Yes |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: JFRHP 0JFRHP
Weight: 1 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
