Intel W3565 Xeon Processor

INTEL Part #/MPN: W3565

DiscTech Item #: INT-W3565-RF-OE

  • Special Order - Ships in 5-10 business days
    Special Order - Ships in 5-10 business days

    This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.


Interface Types: Socket FCLGA1366

Electrical Interface: Clock 3.2 GHz

On-Board Cache: 8MB

Intel W3565 Xeon Processor 8M Cache 3.20 GHz 480 GT/s Intel QPI - Refurbished

Intel W3565 Xeon Processor 8M Cache 3.20 GHz 480 GT/s Intel QPI - Refurbished

Discover the new Intel® Xeon® processor E3 family

Elevating graphics performance in data centers - Data center–based graphics take a huge step forward with the new Intel® Xeon® processor E3-1200 v3 product family. Featuring new Intel® processor microarchitecture (formerly Haswell), these powerful processors transform server capabilities to create vast new possibilities for your data center. Now you can deliver rich visuals and consistently smooth user experiences, while also streamlining your data center.

Optimize graphics in the cloud - New processors from the Intel Xeon processor E3 family are built to support an extended range of cloud-based graphics demands. From virtual hosted desktops to cloud gaming to workstations in the cloud, you can deliver cutting-edge performance per watt and more efficient rendering in the cloud. That’s great news for applications, such as outsourced encoding at scale and device and cloud partitioning.

Stream media to any connected device - Take care of a diverse range of media needs right from your data center. Integrated processor capabilities make smooth work of transcoding various formats for content on demand, user-generated media, live broadcasting, and video conferencing. And by eliminating a hardware component—a discrete graphics card—you’ll capture significant performance efficiencies per watt and benefit from the greater density of video streams.

Run complex video analytics - Go beyond video processing to measure, analyze, and interpret streaming content. For companies investing in big data analytics, new processors deliver the computing power to capture valuable metrics, gain insights, and perform data-intensive tasks like video search indexing, digital surveillance, and automated ads that react to scene changes.


X58 Express I/O Hub

Processor NumberW3565
Intel Smart Cache8 MB
Intel QPI Speed4.8 GT/s
Number of QPI Links1
Instruction Set64-bit
Instruction Set ExtensionsSSE4.2
Embedded Options AvailableNo
Lithography45 nm
VID Voltage Range0.800V-1.225V
Number of Cores4
Number of Threads8
Processor Base Frequency3.2 GHz
Max Turbo Frequency3.46 GHz
TDP130 W
Max Memory Size (dependent on memory type)24 GB
Memory TypesDDR3-800/1066
Number of Memory Channels3
Max Memory Bandwidth25.6 GB/s
Physical Address Extensions36-bit
ECC Memory SupportedYes
Max CPU Configuration1
Package Size42.5mm (1.673in) x 45.0mm (1.771in)
Processing Die Size (mm/in)263/10.354
Number of Processing Die Transistors731 million
Sockets SupportedFCLGA1366
Intel Turbo Boost Technologies1.0
Intel Hyper-Threading TechnologyYes
Intel Virtualization Technology (VT-x)Yes/td>
Intel VT-x with Extended Page Tables (EPT)Yes
Intel 64Yes
Idle StatesYes
Enhanced Intel Speed Step TechnologyYes
Intel Demand Based SwitchingYes
Thermal Monitoring TechnologiesNo
AES New InstructionNo
Trusted Execution TechnologyNo
Execute Disable BitYes

Click here to view the manufacturer's item description/brochure

Alternate MPNs: AT80601002727AB, BX80601W3565

Weight: 2 lb

Warranty: 1 Year DiscTech


Condition Levels Explained

These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
