Intel X25-M Series SSDSA2M080G2GC 80GB SATA SSD


DiscTech Item #: INT-SSDSA2M080G2GC-RF-OE

  • Special Order - Ships in 5-10 business days
    Special Order - Ships in 5-10 business days

    This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.


Capacity: 80GB

Speed: Solid State Memory

Interface Types: SATA

Form Factor: 2.5inx7mm Fits All laptops

Sector Size: 512 / 512e

Sustained Throughput: 250/70

Average Seek Time: 65 µs/85 µs

Electrical Interface: SATA 300 - 3.0Gbps


Intel X25-M Series SSDSA2M080G2GC 80GB 2.5 inches 3Gbps MLC SATA SSD - Refurbished

Intel X25-M Series SSDSA2M080G2GC 80GB 2.5" 3Gb/s Multi-Level Cell Serial ATA Solid-State Disk Drive - Refurbished


This drive is compatible with any server that accepts 2.5in x 7mm SATA drives.

Model NumberSSDSA2M080G2GC
ComponentsIntel NAND Flash Memory Multi-Level Cell (MLC) Technology
Form Factor2.5" 7mm
InterfaceSATA 3.0 3Gb/s
Lithography Type34nm
Advanced Technologies
Enhanced Power Loss Data ProtectionNo
Sequential Read250 MB/s
Sequential Write70 MB/s
Random Read (8GB Span)35000 IOPS
Random Read (100% Span)35000 IOPS
Random Write (8GB Span)6600 IOPS
Random Write (100% Span)300 IOPS
Latency - Read65 µs
Power - Active150 mw (MobileMark 2007 Workload), 2.5 W (64K Sequential Write)
Power - Idle75 mw (DIPM), .06 W (Non-DIPM)
Vibration - Operating2.17 GRMS (5-7000Hz)
Vibration - Non-Operating3.13 GMMS (5-8000Hz)
Shock (Operating and Non-Operating)1,500 G.5 msec
Operating Temperature Range0°C to 70°C
Weightup to 80 ± 2 grams
Mean Time Between Failures (MTBF)1,200,000 Hours
Uncorrectable Bit Error Rate (UBER)1 sector per 10e16
Recommended Customer PriceN/A

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Weight: 1 lb

Warranty: 1 Year DiscTech


Condition Levels Explained

These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
