Intel Xeon E5-2620 V3 2.4GHz CPU Processor

INTEL Part #/MPN: E5-2620V3

DiscTech Item #: INT-E5-2620V3-BN-2M


$54.00
  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

$54.00

Interface Types: Socket FCLGA1356

Electrical Interface: Clock 2.4 GHz

On-Board Cache: 20MB

Intel Xeon E5-2620 V3 / SR207 2.4GHz 6-Core Processor 15MB FCLGA2011-v3 Socket CPU - Brand New

Intel Xeon E5-2620 V3 / SR207 2.4GHz 6-Core Processor 15MB FCLGA2011-v3 Socket CPU - Brand New

DPN: GK3MY 0GK3MY 374-BBHC


Compatibility:

Compatible with servers including, but not limited to..

  • Dell PowerEdge R430 / T430
  • Dell PowerEdge R530
  • Dell PowerEdge R630 / T630
  • Dell PowerEdge R730 / R730XD

Server System R1304BB4DCServer System MCB2224THY1Server System VRN2224THY2Server System VRN2224THY4
Server System R1208WT2GSRServer System R1208WTTGSRServer System R1304WT2GSRServer System R1304WTTGSR
Server System R2208WTTYSRServer System R2208WT2YSRServer System R2208WTTYC1RServer System R2308WTTYSR
Server System R2312WTTYSRServer System R2224WTTYSRServer System S2600CW2RServer System S2600CW2SR
Server System S2600CWTRServer System S2600CWTSRServer System S2600KPRServer Board S2600KPFR
Server Board S2600KPTRServer Board S2600TPFRServer Board S2600TPNRServer Board S2600TPR
Server Board S2600WTTRServer Board S2600WT2RServer Board S2600WTTS1R

ESSENTIALS
Product CollectionIntel® Xeon® Processor E5 v3 Family
Code NameProducts formerly Broadwell
Vertical SegmentServer
Processor NumberE5-2620V3
Lithography22 nm
PERFORMANCE
Number of Cores6
Number of Threads12
Processor Base Frequency2.40 GHz
Max Turbo Frequency3.20 GHz
Cache15MB SmartCache
Bus Speed8 GT/s QPI
TDP85 W
Number of QPI Links2


SUPPLEMENTAL INFORMATION
Embedded Options AvailableYes
MEMORY SPECIFICATIONS
Max Memory Size (dependent on memory type)768GB / 1.5TB
Memory TypesDDR4 1600 / 1866
Max Number of Memory Channels4
Max Memory Bandwidth59GB/s
Physical Address Extensions46-bit
ECC Memory SupportedYes
EXPANSION OPTIONS
Scalability2S
PCI Express Revision3.0
PCI Express Configurationsx4, x8, x16
Max Number of PCI Express Lanes40
PACKAGE SPECIFICATIONS
Sockets SupportedFCLGA2011-3
Max CPU Configuration2
TCase72.6°C
Package Size52.5mm x 45mm
ADVANCED TECHNOLOGIES
Intel Turbo Boost Technologies2.0
Intel Hyper-Threading TechnologyYes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel® TSX-NIYes
Intel 64Yes
Instruction Set64-bit
Instruction Set ExtensionsIntel AVX2
Enhanced Intel SpeedStep TechnologyYes
Intel® Demand Based SwitchingYes
Thermal Monitoring TechnologiesYes
Intel® Flex Memory AccessNo
Intel Identity Protection TechnologyNo
SECURITY & RELIABILITY
Intel AES New InstructionsYes
Secure KeyYes
Intel® OS GuardYes
Trusted Execution TechnologyYes
Execute Disable BitYes

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: E5-2620-V3 GK3MY 0GK3MY 374-BBHC SR207

Weight: 1 lb

Warranty: 2 Month DiscTech

Brand New

Condition Levels Explained

The product is brand new.

2 Month DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
