INTEL Part #/MPN: E5-4660-V4
DiscTech Item #: INT-E5-4660V4-RF-OE
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- In Stock:8Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Interface Types: Socket FCLGA1356
Electrical Interface: Clock 2.2 GHz
On-Board Cache: 32MB
Intel Xeon E5-4660-v4 / SR2SD 2.2 GHz 16 Core 40MB Cache CPU Processor - Refurbished
Intel Xeon E5-4660-v4 / SR2SD 2.2 GHz 16 Core 40MB Cache CPU Processor - Refurbished
ESSENTIALS | |
---|---|
Product Collection | Intel® Xeon® Processor E5 v4 Family |
Code Name | Products formerly Broadwell |
Vertical Segment | Server |
Processor Number | E5-4660-V4 |
Lithography | 14 nm |
PERFORMANCE | |
Number of Cores | 16 |
Number of Threads | 32 |
Processor Base Frequency | 3.00 GHz |
Max Turbo Frequency | 3.00 GHz |
Cache | 40MB |
Bus Speed | 9.6 GT/s QPI |
TDP | 120 W |
Number of QPI Links | 2 |
SUPPLEMENTAL INFORMATION | |
Embedded Options Available | Yes |
MEMORY SPECIFICATIONS | |
Max Memory Size (dependent on memory type) | 1.5TB |
Memory Types | DDR4 1600 / 1866 / 2133/2400 |
Max Number of Memory Channels | 4 |
Max Memory Bandwidth | 68GB/s |
Physical Address Extensions | 46-bit |
ECC Memory Supported | Yes |
EXPANSION OPTIONS | |
Scalability | 4S |
PCI Express Revision | 3.0 |
PCI Express Configurations | x4, x8, x16 |
Max Number of PCI Express Lanes | 40 |
PACKAGE SPECIFICATIONS | |
Sockets Supported | FCLGA2011-3 |
Max CPU Configuration | 4 |
TCase | 83°C |
Package Size | 52.5mm x 45mm |
ADVANCED TECHNOLOGIES | |
Intel Turbo Boost Technologies | 2.0 |
Intel Hyper-Threading Technology | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel® TSX-NI | No |
Intel 64 | Yes |
Instruction Set | 64-bit |
Instruction Set Extensions | Intel AVX2 |
Enhanced Intel SpeedStep Technology | Yes |
Intel® Demand Based Switching | Yes |
Thermal Monitoring Technologies | Yes |
Intel® Flex Memory Access | No |
Intel Identity Protection Technology | No |
SECURITY & RELIABILITY | |
Intel AES New Instructions | Yes |
Secure Key | Yes |
Intel® OS Guard | Yes |
Trusted Execution Technology | Yes |
Execute Disable Bit | Yes |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: SR2SD
Weight: 0.25 lb
Warranty: 1 Year DiscTech
Refurbished
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
