Kingston Fury Beast KF436C18BB-32 / XF3V7J-MIE-FX / Dell F3V7J 32GB DDR4 3600MHz CL18 2Rx8 Dual-Rank Non-ECC Unbuffered 288-Pin RAM Memory
- Brand NewCondition Levels Explained
The product is brand new.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Interface Types: | DDR4 DIMM 288pin |
| Form Factor: | DDR4 UDIMM |
| Electrical Interface: | PC4-25600 |
| RAM: | 32GB |
| Voltage: | 1.1V |
Description
Kingston Fury Beast KF436C18BB-32 / XF3V7J-MIE-FX / Dell F3V7J 32GB DDR4 3600MHz CL18 2Rx8 Dual-Rank Non-ECC Unbuffered 288-Pin RAM Memory - Brand New OEM
Kingston Fury Beast KF436C18BB-32 / XF3V7J-MIE-FX / Dell F3V7J 32GB DDR4 3600MHz CL18 2Rx8 Dual-Rank Non-ECC Unbuffered 288-Pin RAM Memory - Brand New OEM
Description:
Kingston FURY KF436C18BB/32 is a 4G x 64-bit (32GB) DDR4-3600 CL18 SDRAM (Synchronous DRAM) 2Rx8, memory module, based on sixteen 2G x 8-bit FBGA components per module. Each module kit supports Intel® Extreme Memory Profiles (Intel® XMP) 2.0. Each module has been tested to run at DDR4-3600 at a low latency timing of 18-22-22 at 1.35V. The SPDs are programmed to JEDEC standard latency DDR4-2400 timing of 17-17-17 at 1.2V. Each 288-pin DIMM uses gold contact fingers. The JEDEC standard electrical and mechanical specifications are as follows:
JEDEC/XMP TIMING PARAMETERS:
- DDR4-2400 CL17-17-17 @ 1.2V
- DDR4-3600 CL18-22-22 @ 1.35V
- DDR4-3000 CL16-18-18 @ 1.35V
Compatibility
Compatible with any PC that accepts 32GB 3200MHz 288-Pin DDR4 Memory.
Designed for:
Dell Alienware Aurora R15 R16
Specifications
| Kingston Fury HyperX / Beast Product Specifications | |
|---|---|
| Dell Part# | KF436C18BB/32 |
| Alt Part# | XF3V7J-MIE-FX / Dell F3V7J |
| Device Type | DDR4 RAM |
| Capacity | 32GB |
| Speed | 3200MHz |
| CL(IDD) | 18 cycles |
| Row Cycle Time (tRCmin) | 45.75ns(min.) |
| Refresh to Active/Refresh Command Time (tRFCmin) | 350ns(min.) |
| Row Active Time (tRASmin) | 32ns(min.) |
| UL Rating | 94 V -0 |
| Operating Temperature | 0° to 85° C |
| Storage Temperature | -55° to 100° C |
| Power Supply | 1.1V Typical |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: F3V7J 0 F3V7J XF3V7J-MIE-FX
Weight: 0.5 lb
Warranty: 1 Year DiscTech
