Kingston Fury Beast KF548C38BB-16 / XKHFXM-MIA-A / Dell KHFXM 16GB DDR5 4800MHz CL38 1Rx8 Single-Rank Non-ECC Unbuffered 288-Pin RAM Memory

Kingston Fury Beast KF548C38BB-16 / XKHFXM-MIA-A / Dell KHFXM 16GB DDR5 4800MHz CL38 1Rx8 Single-Rank Non-ECC Unbuffered 288-Pin RAM Memory
Interface Types: | DDR4 DIMM 288pin |
Form Factor: | DDR5 UDIMM |
Electrical Interface: | PC5-38400 DDR5-4800 MT/s |
Voltage: | 1.1V |
Description
Kingston Fury Beast KF548C38BB-16 / XKHFXM-MIA-A / Dell KHFXM 16GB DDR5 4800MHz CL38 1Rx8 Single-Rank Non-ECC Unbuffered 288-Pin RAM Memory - Brand New OEM
Kingston Fury Beast KF548C38BB-16 / XKHFXM-MIA-A / Dell KHFXM 16GB DDR5 4800MHz CL38 1Rx8 Single-Rank Non-ECC Unbuffered 288-Pin RAM Memory - Brand New OEM
Description:
Kingston FURY KF548C38BB-16 is a 2G x 64-bit (16GB)
DDR5-4800 CL38 SDRAM (Synchronous DRAM) 1Rx8, memory
module, based on eight 2G x 8-bit FBGA components per module.
The module supports Intel® Extreme Memory Profiles (Intel®
XMP) 3.0. Each module has been tested to run at DDR5-4800 at a
low latency timing of 38-38-38 at 1.1V. Additional timing parameters
are shown in the Plug-N-Play (PnP) Timing Parameters section
below. Each 288-pin DIMM uses gold contact fingers. The
JEDEC standard electrical and mechanical specifications are
as follows:
JEDEC/XMP TIMING PARAMETERS:
- Default (Plug N Play): DDR5-4800 CL38-38-38 @ 1.1V
- XMP Profile #1: DDR5-4800 CL38-38-38 @ 1.1V
Compatibility:
Compatible with any PC that accepts 16GB 4800MHz 288-Pin DDR5 Memory.
Designed for:
Dell Alienware Aurora R15 R16
Specifications
Kingston Fury HyperX / Beast Product Specifications | |
---|---|
Dell Part# | KF548C38BB-16 |
Alt Part# | XKHFXM-MIA-A |
Device Type | DDR5 RAM |
Capacity | 16GB |
Speed | 4800MHz |
CL(IDD) | 32 cycles |
Row Cycle Time (tRCmin) | 48ns(min.) |
Refresh to Active/Refresh Command Time (tRFCmin) | 295ns(min.) |
Row Active Time (tRASmin) | 29ns(min.) |
UL Rating | 94 V -0 |
Operating Temperature | 0° to 85° C |
Storage Temperature | -55° to 100° C |
Power Supply | 1.1V Typical |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: KHFXM 0KHFXM XKHFXM-MIA-A
Weight: 0.5 lb
Warranty: 1 Year DiscTech
Condition
Brand New
Warranty
1 Year DiscTech Warranty
