Liqid Element LQD4500 8-Port M.2 NVMe SSD to PCIe 4.0 x16 Adapter Card AIC with PEX88048 Controller FHFL
- New Open BoxCondition Levels Explained
The product is new, either in resealed factory packaging or replacement packaging. (Typically on hard drives this means that the drives have been re-bagged).The item may be a customer returned item.
- In Stock:43Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Interface Types: | PCIe |
Description
Liqid Element LQD4500 8-Port M.2 NVMe SSD to PCIe 4.0 x16 Adapter Card AIC with PEX88048 Controller FHFL - Open Box
Liqid Element LQD4500 8-Port M.2 NVMe SSD to PCIe 4.0 x16 Adapter Card / 24 GB/s / 4m IOPS / AIC / PEX88048 Controller / FHFL / Full-Height Full-Length / Up to 32.7TB / Bifurcation Supported / IO Accelerator / TCL 3D NAND / - New Pull
Bare Cards / No NVMe SSD included / Use of thermal paste or pad on controller and NVMe SSD recommended
Unleash applications from their data restraints with the LQD4500 Gen-4 PCIe AIC.
The Liqid Element LQD4500 PCIe Add-in-Card (AIC), aka the “Honey Badger" for its fierce, lightning fast data speeds, delivers Gen-4 PCIe performance with up to 4m IOPS, 24 GB/s throughput, ultra-low transactional latency of just 20 µs, in capacities up to 32TB.
In data-driven environments, unlocking the full potential of data performance is paramount. Introducing the Liqid Element LQD4500 IO Accelerator — an advanced storage solution engineered to shatter performance barriers and redefine what’s possible. Designed to deliver uncompromised data IO performance and responsiveness, the LQD4500 empowers you to accelerate results.
With the capability to deliver an astounding 4 million IOPS of random read performance, coupled with over 26 GB/s of read throughput, it surpasses conventional SSDs, providing the robust foundation your data-intensive applications demand. The ultralow transactional latency of just 10 microseconds ensures that every data interaction occurs at the speed of now.
Storage demands are experiencing exponential growth, and with capacities reaching up to a remarkable 32 terabytes, the LQD4500 equips you to handle vast datasets without compromise. Whether you’re navigating complex simulations, conducting expansive analytics, or managing rich multimedia content, the LQD4500 offers substantial headroom.
Key Features
- Ultra-High Performance
- PCIe 4.0 x16 Interface
- NVMe 1.3 Protocol
- High Capacity, up to 32 TB
- Single Width FHFL
- Plug-n-Play Compatibility
- UEFI Boot Support
- Enterprise Grade Reliability
- Power Loss Data Protection
- Active Thermal Throttling
- Active Power Management
- Advanced ECC and Data Protection
- Advanced Error Recovery
- Active Telemetry Monitoring
- Low Overhead Architecture
- No Host CPU or DRAM Off Load
- Software or OS RAID Supported Data Protection
Specifications
| Specification | Details |
|---|---|
| Model | Liqid LQD4500 IO Accelerator |
| Raw Capacity | Up to 32TB |
| NAND Type | TLC 3D NAND |
| Read Bandwidth | Up to 26GB/s Throughput |
| Write Bandwidth | Up to 13GB/s Throughput |
| Random 4K Read IOPS | Up to 4M IOPS |
| Random 4K Write IOPS | Up to 900K IOPS |
| Min Read Latency | 70μs |
| Min Write Latency | 10μs |
| Protocol | NVMe 1.3 |
| Bus Interface | PCI Express 4.0 x16 |
| Endurance | Up to 61.53 PBW / 2 DWPD* |
| Security | 256-bit AES Data Encryption |
| Weight | 20 oz |
| Warranty | 3 years or maximum endurance used |
| Form Factor | FHFL Single Width |
| Operating Temperature | Op: 0 to 55°C / Non-Op: -40 to 75°C |
| Power | Active: 12VDC / ~75W |
| Airflow | Min 400 LFM |
| Humidity | 5% to 95% (non-condensing) |
| Altitude | 0 ft to 10,000 ft |
| Operating Systems | Windows, RHEL, SLES, CentOS, Solaris, SUSE, VMware |
| Agency & Safety | UL, CB, CE, CCS, KCC, HF, JEDEC, CNS, VCCI, FCC Part 15, Subpart B, and CISPR 32 for a Class A device |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: WDFFP 0WDFFP
Weight: 3 lb
Warranty: 1 Year DiscTech
Condition
New Open Box
Warranty
1 Year DiscTech Warranty
