Maxtor 5A250J0 250GB Ultra ATA133 Hard Drive

Maxtor Part #/MPN: 5A250J0

DiscTech Item #: MAX-5A250J0-RF-OE

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.


Enterprise Grade

Capacity: 250GB

Speed: 5,400RPM

Interface Types: IDE ATA 3.5in

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 46

Average Seek Time: ≤10.0

Electrical Interface: EIDE Ultra ATA133 133MBps

On-Board Cache: 2MB

Maxtor MaXLine II 5A250J0 250GB 5.4K 133MB/s Ultra ATA133 Hard Drive - Refurbished

Maxtor MaXLine II 5A250J0 250GB 5,400 RPM 133MB/s Ultra ATA133 Hard Drive - Refurbished

MaXLine™ II and MaXLine Plus II
Industry-leading Capacity, Performance, And Reliability for Midline Applications

MaXLine drives provide large-capacity ATA disk storage so reliable, fast and cost-effective, it leaves traditional tape and optical solutions in the dust. At prices about the same as tape and optical, but with far superior capacity and access times, ATA drives are ideal for 24x7-duty situations where you may not need stored data all the time, but when you do need it, you need it now.
At 250GB and 300GB, MaXLine ATA drives provide greater storage capacity than regular ATA drives, and they offer the added benefit of ultra-reliability. For midline and other low-I/O secondary storage applications, they’re rated at better than 1 million hours MTTF. Maxtor stands behind MaXLine drives with a 5-year limited warranty.


  • 5400 RPM
  • 250GB and 300GB capacities
  • ATA/133 interface
  • Max sustained data transfer rate up to 46MB/sec
  • ≤10.0ms average seek time
  • Max burst transfer speeds up to 133MB/sec
  • 2MB cache buffer
  • Rated to exceed 1 million hours MTTF for midline and other low-I/O secondary storage applications
  • Proven in OEM NAS appliances
  • S.M.A.R.T. compliance features


This drive is compatible with any server that accepts 3.5"x1" (LFF) Ultra ATA133 drives.

Model number5A250J0
InterfaceParallel ATA—ATA/133 2MB Buffer
Rotational Speed5400 RPM
Buffer (Cache) Size2MB
Maximum Burst Transfer Rate 133MB/sec
Maximum Sustained Transfer (Rate per Single Drive)46MB/sec
Average Seek (ms)≤10.0
Drive Configuration
Discs/Heads (Max) 4/8
Bytes per Sector/Block512
Logical CHS16,383/16/63
Start/Stop Cycles (min) >50,000
Component Design Life (min)5 years
Data Errors (non-recoverable)<1 per 10E 15 bits read
Annualized Return Rate (ARR)<1.0%
Power Requirements
Mode 5V
Seek (mA)593
Idle (mA590
Standby (mA)149
Environmental Limits
Idle (sound power: bel)
Performance Seek (sound power: bel)

Operating (°C)
Non-operating (°C)

5 to 55
-40 to 71
Operating Mechanical Shock 2msec (G)
Non-operating Mechanical Shock 2msec (G)

Physical Dimensions
Height (max mm 26.1
Width (typical mm)101.6
Length (max mm) 147.0
Weight (Max LB/g)1.34/610

Click here to view the manufacturer's item description/brochure

Weight: 1.8 lb

Warranty: 1 Year DiscTech


Condition Levels Explained

These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
