Micron 5200 Max MTFDDAK1T9TDN / MTFDDAK1T9TDN-1AT1ZABDB / Dell YYJJT 1.92TB eTLC TCG SATA Solid State Drive

Micron 5200 Max MTFDDAK1T9TDN / MTFDDAK1T9TDN-1AT1ZABDB / MTFDDAK1T9TDN-1AT1ZABYY / Dell YYJJT / 0YYJJT 1.92TB 2.5-Inch 6Gbps eTLC Mixed Use TCG SATA Solid State Drive - Brand New

Micron 5200 Max MTFDDAK1T9TDN / MTFDDAK1T9TDN-1AT1ZABDB / MTFDDAK1T9TDN-1AT1ZABYY / Dell YYJJT / 0YYJJT 1.92TB / 1920GB 2.5" 6.0 Gb/s eTLC / Enterprise Triple-Level Cell / MU / Mixed Use 5-DWPD / Drive Writes Per Day TCG-E / Trusted Computing Group SATA / Serial ATA SSD / Solid State Drive - Brand New

Micron 5200 Series of SATA SSDs

Join the SOLID storage revolution. Because spinning media is winding down.
There’s an easy way to speed up business-critical workloads that cripple hard drives: The Micron® 5200 series of SATA SSDs. Engineered on industry-leading 64-layer 3D NAND, the Micron 5200 SSD delivers best-inclass performance and capacity on the same proven architecture as the 5100 series.*

Designed for virtualized workloads that power your business, such as OLTP, BI/DSS, VDI, block/object, media streaming and more, the lowlatency Micron 5200 series of SSDs eliminates storage bottlenecks with fast, consistent performance — and a lower total cost of ownership.

A single Micron SSD allows you to get 3X more performance than an entire shelf of 24 10K RPM hard drives.** Imagine the impact — across your entire data center.

Key Features

• Leading Performance
  Industry-leading sequential reads/writes paired with 95,000 IOPS random reads and best-in-class random writes up to 75,000 deliver a compelling performance advantage over hard drives and competing SATA SSDs.‡
• Leading Capacity and TCO
  Capacities up to nearly 8TB — all on industry-leading, 64-layer 3D NAND for a cost-optimized SATA platform that’s uniquely competitive against hard drives.
• Leading Reliability
  Improved reliability with the industry’s highest published MTTF and lowest annualized drive failure rate for SATA enterprise SSDs according to data sheet specifications.‡‡
• Same Trusted, Proven Architecture
  Same controller. Same components. New NAND. The result is easy quals, better performance and better value.



Solid, Secure, Feature-Rich SSDs

• Secure Firmware
  Incorporates secure digital signatures and boot-time attestation, which help to protect storage devices against low-level attacks

FEATURES

• Micron® 3D TLC NAND Flash
• Three performance/endurance levels
  • ECO
  • PRO
  • MAX
• SATA 6 Gb/s interface
• ATA modes supported
  • PIO mode 3, 4
  • Multiword DMA mode 0, 1, 2
  • Ultra DMA mode 0, 1, 2, 3, 4, 5, 6
• 512-byte sector size support
• Hot-plug capable
• Native command queuing support with 32-command slot support
• ATA-8 ACS-3 revision 5 command set compliant
• ATA security feature command set and password login support
• Security erase command set: fast and secure erase
• Performance (steady state)
  • Sequential 128KB read: Up to 540 MB/s
  • Sequential 128KB write: Up to 520 MB/s
  • Random 4KB read: Up to 95,000 IOPS
  • Random 4KB write: Up to 75,000 IOPS
• Quality of Service
  • Read/Write (99.9%): 200µs/300µs (<2TB)
  • Read/Write (99.999%): 1000µs/700µs (<2TB)
• Endurance : Total bytes written (TBW)
  • Up to 17600TB
• Reliability
  • MTTF: 3.0 million device hours
  • Static and dynamic wear leveling
  • Uncorrectable bit error rate (UBER): <1 sector per 1017 bits read
  • End-to-end data protection
  • Enhanced power-loss data protection with data protection capacitor monitoring
• Self-monitoring, analysis, and reporting technology (SMART) command set
• Capacity4 (unformatted): 240GB, 480GB, 960GB, 1920GB, 3840GB, 7680GB
• Mechanical:
  • 2.5-inch x 7.0mm form factor
• RoHS-compliant package
• Secure field-upgradeable firmware with digitally signed firmware image
• Power consumption: <6.0W (TYP, 5V only)
• Operating temperature
  • Commercial (0°C to 70°C)5

* The Micron 5200 was the first enterprise SSD available to purchase with 64‐layer 3D NAND. Performance comparison based on public data sheet specifications for GB/s throughput and random write IOPS performance for comparable enterprise SATA 2.5‐inch product family as of the date of this document’s publication. Actual performance may vary.

** Based on IOPS performance of 24 hard drives (300GB, 10K RPM, SAS) compared to a single 960GB Micron 5100 PRO SSD in an OLTP workload environment. Results do not reflect differences in capacity and hard drives were not short‐stroked. Actual performance may vary. For conceptual purposes only.

‡ Based on maximum data sheet specifications (steady state) across the Micron 5200 product line. Performance varies by model and capacity. Visit the Micron 5200 product page for additional product details.

‡‡ Per public data sheet specifications, the Micron 5200 SSD has a mean time to failure (MTTF) of 3 million device hours, compared to 2 million hours for SATA enterprise SSDs. Converting these numbers to annualized failure rates gives the Micron 5200 a 0.29% annualized failure rate versus 0.44% for competing drives. Enhanced reliability is the foundation for consistent, predictable performance.

All information is provided on as “AS IS” basis without warranties of any kind, including any implied warranties, warranties of merchantability or warranties of fitness for a particular purpose.

Designed for virtualized workloads that power your business, such as OLTP, BI/DSS, VDI, block/object, media streaming and more.
Compatible with any server that accepts a 2.5" SATA Hard Drive

ROHS Compliant

Alternate MPNs: MTFDDAK1T9TDN-1AT1ZABDB YYJJT 0YYJJT

Weight: 1 lb

Warranty: 1 Year DiscTech

Brand New

1 Year DiscTech Warranty
