NF5023-CM703T SAS Hard Drive Kit

NEC Part #/MPN: NF5023-CM703T

DiscTech Item #: NEC-NF5023-CM703T-BN-OE

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.


Enterprise Grade

Capacity: 500GB

Speed: 7,200RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 147

Average Seek Time: 8.5 / 9.5

Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps

On-Board Cache: 64MB

NEC NF5023-CM703T 500GB 7.2K 6.0Gbps SAS / Serial Attached SCSI Hard Drive Kit - Brand New OEM

NEC NF5023-CM703T 500GB 7200K RPM 6.0Gbps SAS / Serial Attached SCSI Enterprise Hard Drive Kit - Brand New OEM

Alt MPNs: 9YZ262-047, 243-421593-411, 711048800


Compatible with NEC Storage Disk Arrays

NEC Storage D4-30

NEC Storage D4-30i



Drive specification


Formatted Gbytes (512 bytes/sector)


Bytes per sector


Spindle speed (RPM)


I/O data transfer rate (MBps)


Cache buffer


Interface Type

6.0Gbps SAS

Seek time (read / write) ms

8.5 / 9.5

Average Latency


Dimensions (HxLxW) mm

26.1 / 147 / 101.85


0.640 kg

Operating Shock (Read)

70G, 2ms

Non-operating Shock

300G, 2ms

Temperature - Operating

5C -60C

Temperature - Non-operating

-40C - 70C


1,200,000 hrs

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: 243-421593-411 711048800 9YZ262-047

Weight: 1.8 lb

Warranty: 1 Year DiscTech

Brand New

Condition Levels Explained

The product is brand new.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
