NETGEAR Part #/MPN: JFS524
DiscTech Item #: NET-JFS524-BN-FW
Item is out of stock. Please call for alternatives.
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:Factory Warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Interface Types: Ethernet RJ45
Electrical Interface: Ethernet Fast - 100Mbps
On-Board Cache: 2MB
Bays/Ports/Slots: 24
U Height: 1U
Voltage: 110-240V Multi
NetGear ProSAFE Fast Ethernet Unmanaged Switch Series JFS524 / JFS524v2 24-Port 10/100 Ethernet Switch - Brand New
NetGear ProSAFE Fast Ethernet Unmanaged Switch Series JFS524 24-Port 10/100 Ethernet Switch - Brand New
Alt Model/Part No.: JFS524v2
ProSAFE® Fast Ethernet Rack Mountable Switches
The NETGEAR® Fast Ethernet Unmanaged Switches series are purposely designed, well built and rigorously tested for small and medium-sized networks where reliability and performance are the keys while Plug-N-Play connectivity and operational cost savings are the must-haves. With a 1U form factor, they can be placed on the desktop or rack-mounted with the included rack-mount kit for professional installation.
The JFS516 and JFS524 come with 16 and 24 ports 10/100Mbps copper ports respectively. They offer energy efficiency features and are compliant with the IEEE 802.3az standard. Both models are fanless for silent operation, business class rugged.
Instant Network Connectivity for Your Small Business and Home Office
- Non-blocking switching architecture forwards and filters packets at full wire-speed for maximum throughput
- Up to 24 ports, each delivering up to 200Mbps of dedicated network bandwidth to servers, PCs and newtork devices
- Energy Efficient Ethernet (IEEE802.3az) for optimized power saving
- Rugged metal case and fanless design for reliable and silent operation
Business-Class, Built with Performance and Reliability
- Plug-and-play—begins working as soon as it’s powered on
- Auto MDI/MDI-X automatically adjusts for straight-through or crossover cables
- Auto Sensing and IEEE 802.3 Nway Auto Negotiation
- IEEE 802.3x Flow Control
- IEEE 802.1p QoS for traffic prioritization
- Intelligent LEDs for port link status and activity
- Compact size for the desktop or for mounting in a standard 19 -inch rack
| Fast Ethernet Unmanaged Switch Series | |
|---|---|
| Model/Part No. | JFS524 |
| Alt Model/Part No. | JFS524v2 |
| Speed | 10/100Mbps Fast Ethernet |
| Number of Ports | 24 |
| PoE Ports | N/A |
| Loop Detection | N/A |
| Short cable power saving | Yes |
| Energy Efficient Ethernet Support (IEE802.3az) | Yes |
| Jumbo Frame Support | N/A |
| Queue WRR Ratio | 8:4:2:1 |
| MAC Table Size | 8K |
| Packet buffer size | 2Mb |
| IEEE 802.1p QoS | Yes |
| Dimensions (W x D x H) @mm | 280 x 126 x 44 |
| Weight (kg) | 1.00 |
| Max Power Consumption | 4.0W |
| Max Operating Temperature | 50° C |
| MFBF (hours) | 2,940,540 |
| FCC Class | A |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: JFS524v2
Weight: 2.5 lb
Warranty: Factory Warranty
Brand New
The product is brand new.
Factory Warranty Warranty
