NetGear RN628X00-100NES 8-Bay NAS Array

NETGEAR Part #/MPN: RN628X00-100NES

DiscTech Item #: NET-RN628X00-100NES-BN-5Y

  • Special Order - Ships in 5-10 business days
    Special Order - Ships in 5-10 business days

    This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.


Enterprise Grade

Interface Types: SATA, USB 3.0, eSATA External, Ethernet RJ45

Encryption/SED Supported

Electrical Interface: Ethernet 10Gigabit - 10Gbps

On-Board Cache: 8GB

Bays/Ports/Slots: 8

Wattage/VA: 250W

Voltage: 110-240V Multi

Netgear ReadyNAS 628X RN628X00-100NES 8-Bay SATA Quad Core 10GbE NAS Array - Diskless - Brand New

Netgear ReadyNAS 628X RN628X00-100NES Ultimate Performance 8-Bay SATA / Serial ATA Dual Core 10GbE Desktop Model NAS / Network Attached Storage Array - Diskless - Brand New

NetGear ReadyNAS RN628X00-100NES 8-bay Network Attached Storage Array includes ...

  • Intel D-1521 Quad Core 2.4GHz Xeon Hyper Threaded Server Processor
  • 8GB DDR4 ECC
  • 3 x USB 3.0 (1 front, 2 rear)
  • 1 x eSATA Expansion ports
  • 2 x Ethernet RJ45 1GbE LAN ports
  • 2 x Ethernet RJ45 10GbE LAN ports
  • 8 Drive Bays
  • Accepts 3.5" SATA and SAS Hard Drives and Solid State Drives
  • AES 256-bit Encryption Capable

NetGear ReadyNAS 620 Series Network Attached Storage (NAS)

Ultimate performance Data Storage at the Speed of 10 Gigabit
10 Gigabit Ethernet is quickly becoming the standard for business networks, driven by faster computing end-points and the proliferation of wireless mobile devices. The RN620 meets the demands of the next generation network by integrating dual 10 Gigabit Ethernet interfaces, avoiding networking bottlenecks, and 4K video multi-streaming and real-time transcoding for ultimate streaming performance. ReadyNAS 620 is available in 6 and 8 Bay for a total storage capacity of 80TB or up to130TB with expansion module, up to 120 users, for optimized usage in high-demanding environments such as creative studios, company headquarters or large branch offices.

All ReadyNAS are built on the revolutionary ReadyNAS OS 6 operating system and next-gen BTRFS file system. A best-in-class 5 levels of data protection - X-RAID, Unlimited Snapshots, Bit rot protection, real-time anti-virus and easy offsite replication work in concert to securely protect your data from common risks.

All ReadyNAS systems utilize proprietary ReadyCLOUD technology. With ReadyCLOUD, remotely accessing and sharing files in your own secure private cloud has never been easier. No VPN setup, no port forwarding, no dynamic DNS required.

Featuring an architecture powered by the blazing fast quad core hyper threaded Intel Xeon server processors along with DDR4 ECC memory, the RN620 is the no compromise, high performing data storage systems of choice for businesses that need the ultimate in capacity, performance and security

All Inclusive Solution for Data Sharing, Storing & Securing

  • File Sharing:
    Unified storage platform for sharing files between Windows, Mac and Linux-based computers
  • Hard Drive Redundancy:
    RAID redundancy with automatic expansion and unlimited data snapshots for point-in-time restore.
  • Cloud Collaboration:
    Share selected folders and files with ReadyCLOUD with partners, clients or internal teams
  • Backup & Recovery:
    ReadyDR disaster recovery solution based on block level replication technology
  • High Scalability:
    ReadyNAS grows with your business data with 5Bay expansion chassis availability
  • Virtualization:
    Thin provisioning, iSCSI support and certified with VMware

Key Business Features

  • Automatic Backup & Sync:
    Using the ReadyCLOUD app for PC, scheduled protection is easier than ever before
  • Bit Rot Protection:
    A proprietary technology protecting your files from unplanned degradation
  • Unlimited Snapshots:
    Unlimited data snapshot capability for on-box protection and flexible data recovery
  • X-RAID & Instant Provisioning:
    Easily expand capacity and feel confident knowing that data is always protected
  • Cloud-managed Replication:
    Maintain data sets in multiple locations or ensure protection of data from remote or branch office locations
  • iSCSI and Thin Provisioning:
    Powerful tools for a business taking advantage of virtual infrastructures
  • Anti-virus & Encryption:
    Keep data protected from outside threats and safe from prying eyes
  • Modern GUI and Cloud/Remote Access from Anywhere:
    Sleek modern interface and patented technology for secure remote access without configuration effort

ReadyNAS Solutions

File Sharing:
These days, running a successful business often depends on successful file sharing—application data, virtual images, client files, email, all the digital files that make your business go. With ReadyNAS, you finally have an advanced and easy-to-use solution for centralizing, securing, and sharing those critical assets. Faster processors mean more simultaneous users can access unified storage—across PC, Mac and Linux environments. ReadyCLOUD and full Dropbox integration make it easier than ever to sync your important files, photos or videos across all of your web connected devices.

Unlimited snapshots give you complete control over the past, present, and future of your data. This enterprise-class feature copies any point of time in the file system, can be manually or automatically scheduled, and can restore any version with a simple click. Other data protection innovations for disk-based storage like Real Time Anti-Virus and Encryption bring new confidence to the integrity of your data and back-ups.

Disaster Recovery:
The custom-built ReadyNAS OS protects stored data with automatic RAID configuration, the continuous security of Unlimited Snapshots, and easy-to-manage Cloud Replication. By maintaining multiple copies of vital data through cloud replication, it makes it easy for you to move data offsite to protect against natural disasters and theft.

With Unlimited Snapshots, thin provisioning, and improved iSCSI support, ReadyNAS delivers a virtualization platform with next generation features at an affordable price.

Netgear ReadyNAS 628X
Model NumberRN628X00-100NES
CPUIntel D-1521 Quad Core 2.4GHz Xeon
Hyper Threaded Server Processor
Memory8GB DDR4 ECC
Drive Bays8
Drive Types SupportedSATA/SSD 2.5” or 3.5”
Hot Swappable DrivesYes
Tool-less 3.5" disk installationYes
eSATA Expansion Ports1
Internal Capacity80TB
Gigabit LAN Ports2 Gigabit LAN ports
10Gbps LAN Ports2x 10GBase-T
USB Ports3 x USB 3.0 (1 Front, 2 Rear)
Power SupplyInternal 250W input 100-240V AC, 50/60Hz
BTU at Full power supply utilization130.6W
446 BTU/hr
Power consumption: Operation85.6W
Power consumption: (Wake on LAN)348mW
Power consumption: (Power Off)341mW
2-Line LCD DisplayYes
Push Button NavigationYes
Fan (mm)120
Dimensions DxWxH (mm)288.55 x 192 x 319
Weight (kg)9.38kg
ProSUPPORT Service Packs Available
  On Call 24x7
1-year: PMB0313
3-year: PMB0333
5-year: PMB0353
Bluetooth dongle Yes

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: RN628X00

Weight: 21 lb

Warranty: 5 Year Manufacturer
