Philips Signage E-Line BDL3260EL 32-Inch Commercial LED Display Monitor


DiscTech Item #: PHI-BDL3260EL-BN-3Y

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.


Interface Types: Ethernet RJ45, DVI-D, DisplayPort, HDMI, VGA, Composite, Component, 3.5mm Headphone, Serial RS-232 DB9

Voltage: 110-240V Multi

Resolution: 1920x1080

Philips BDL3260EL Signage Solutions E-Line 32-Inch Commercial Edge-lit LED Full HD Display Monitor - Brand New

Philips Signage Solutions E-Line BDL3260EL / A8223391 32" Commercial Edge-lit LED / Light emitting diodes Full HD / High Definition 1920 x 1080 Pixel Smart Control Display / Monitor - Brand New

E-Line Display
With this energy efficient Signage Solution display, you will enjoy all the benefits of state-of-the-art connectivity and content management possibilities while being ensured that remote management safeguards the lowest cost of ownership

Connect with your audience 24/7
With the future proof Smart Collection

  • 32”
  • Edge-lit LED
  • Full HD

Manage and control your network remotely via SmartControl
SmartControl lets you remotely control and manage your network of displays via RJ45 and RS232C. Easily fine-tune all display settings including resolution, brightness, contrast and cloning of your settings over your complete network.

Free and easy-to-use content management with SmartCMS
Free and easy-to-use content management system that works exclusively with Philips Sigage Solutions displays to manage your digital signage content. With SmartCMS you can create and schedule your own content over 24 hours every day. Simply create your network, design your content, schedule your playlist and you are ready to play!

Connect and control your content via the cloud with HTML5
Connect and control your content via the cloud with the integrated HTML5 browser. Design your signage content online and connect it with a display or with your complete network. Simply plug in a RJ45 internet cable for network connection, connect the display with the dedicated url-address and you are ready to play your cloud based content.

Keep your content up and running with FailOver
Keeping your content up and running is critical for demanding commercial applications. While it is unlikely you will face a content disaster, FailOver provides 24/7 protection with a revolutionary technology that plays back-up content on screen in the event of a media player failure. FailOver automatically kicks in when the primary input fails. Simply select a primary input connection and a FailOver connection and your ready for instant protection.

Schedule what you want, when you want with SmartPlayer
Turn your USB into a true cost effective digital signage device. Simply save your content (video, audio, pictures) on your USB and plug into your display. Create your playlist and schedule your content via the on screen menu, and enjoy your own created playlists anytime, anywhere.

SmartPower for energy saving
The backlight intensity can be controlled and pre-set by the system to reduce the power consumption by up to 50%, which saves substantially on energy costs.

Designed for 24/7 operation
Because business never sleeps, our signage displays are designed for 24/7 use. Taking advantage of superior components to ensure a higher level of quality, you can count on this range of models for complete around-the-clock reliability.

Full HD LED technology for brilliant images
White LED's are solid state devices which light up to full, consistent brightness faster saving startup time. LED's are free from mercury content which allows for eco-friendly recycling and disposal process. LED's allow for better dimming control of LCD backlight, resulting in super high contrast ratio. It also gives superior color reproduction thanks to consistent brightness across the screen.

IPS wide view technology for image and color accuracy
Philips IPS displays uses an advanced technology which gives you extra wide viewing angles of 178/178 degree, making it possible to view the display from almost any angle - even in portrait mode. IPS displays gives you remarkably crisp images with vivid colors, especially suitable for professional video wall and menuboard applications which demand color accuracy and consistent brightness at all times.

Connect your display and start sharing with DLNA
Simply share & stream content from your mobile device or media player to your display with all DLNA compliant media devices. Connect each display with an ethernet cable and manage your content real time within your local network. Simply connect your display and start sharing.

Signage Solutions E-Line Display
Model NumberBDL3260EL
Alt Model NumberA8223391
Diagonal Screen Size (in/mm)31.55 inch/80 cm
Panel Resolution1920 x 1080
Optimum Resolution1920 x 1080 @ 60Hz
Brightness400 cd/m
Contrast ratio (typical)1300:1
Dynamic contrast ratio500,000:1
Aspect ratio16:9
Response time (typical)25 ms
Pixel pitch0.36 x 0.36 mm
Display colors16.7 million
Viewing angle (horizontal/vertical)178/178 degree
Picture enhancement
  • 3/2 - 2/2 motion pull down
  • 3D Combfilter
  • Motion compens. deinterlacing
  • 3D MA deinterlacing
  • Dynamic contrast enhancement
  • Dimensions
    Set Width750.2 mm
    Set Height444.6 mm
    Set Depth69 mm
    Bezel width24.4 mm
    Product weight11.4 kg
    VESA Mount400 x 200 mm
    Smart Insert mount100 x 100 mm
  • Portrait
  • Landscape
  • Tiled MatrixUp to 10 x 10
    Keyboard control
  • Hidden
  • Lockable
  • Signal Loop Through
  • DVI
  • VGA
  • RS232
  • IR Loopthrough
  • DisplayPort
  • Network controllable
  • RJ45
  • RS232
  • One Wire (HDMI-CEC)
  • HDMI (One Wire)
  • Energy saving functionsSmart Power
    Ease of installation
  • Smart Insert
  • AC Out
  • Screen saving functionsPixel Shift, Low Bright
    Other convenienceCarrying handles
    Included accessories
  • Remote Control
  • Batteries for remote control
  • AC Power Cord
  • VGA cable
  • User manual on CD-ROM
  • Quick start guide
  • RS232 cable
  • Tiled MatrixBM03241 (Optional)
    Keyboard controlColourCalibrationKit (CCK4601)
    On-Screen Display Languages
  • English
  • French
  • German
  • Spanish
  • Polish
  • Turkish
  • Russian
  • Italian
  • Simplified Chinese
  • Traditional Chinese
  • Arabic
  • Japanese
  • Regulatory approvals
  • CE
  • FCC, Class B
  • UL/cUL
  • CCC
  • C-Tick
  • RoHS
  • GOST
  • BSMI
  • CB
  • J-Moss
  • PSE
  • VCCI
  • Connectivity
    Video input
  • DisplayPort (1.2)
  • HDMI (x2)
  • DVI-D
  • VGA (Analog D-Sub)
  • USB
  • Component (RCA)
  • Composite (RCA)
  • Video output
  • DisplayPort
  • DVI-I
  • VGA (Analog D-Sub)
  • Audio input
  • 3.5 mm jack
  • Audio Left/Right (RCA)
  • Audio output
  • Audio Left/Right (RCA)
  • External speaker connector
  • External control
  • IR (in/out) 3.5 mm jack
  • RJ45
  • RS232C (in/out) 2.5 mm jack
  • Supported Display Resolution
    Computer formats
  • 1920 x 1200, 60Hz
  • 1920 x 1080, 60Hz
  • 1440 x 900, 60Hz
  • 1366 x 768, 60Hz
  • 1360 x 768, 60Hz
  • 1280 x 800, 60Hz
  • 1280 x 768, 60Hz
  • 1024 x 768, 60Hz
  • 800 x 600, 56, 60, 72, 75Hz
  • 640 x 480, 60, 67, 72, 75Hz
  • Video formats
  • 1080p, 50, 60Hz
  • 1080i, 50, 60Hz
  • 720p, 50, 60Hz
  • 576i, 50Hz
  • 576p, 50Hz
  • 480p, 60Hz
  • 480i, 60Hz
  • Power
    Consumption (On mode)48.57 W (EnergyStar 6.0 test method)
    Standby power consumption<0.3 W
    Mains power100 ~ 240 VAC, 50 ~ 60 Hz
    Operating conditions
    Temperature range (operation)0 ~ 40 °C
    Temperature range (storage)-20 ~ 60 °C
    Relative humidity20 ~ 80 %
    Altitude0 ~ 3000 m
    MTBF60,000 hour(s)
    Built-in speakers2 x 10 W RMS
    Multimedia Applications
    USB Playback Audio
  • AAC
  • AIF
  • AIFF
  • M4A
  • MP3
  • WAV
  • WMA
  • ASF
  • LPCM
  • M3U
  • MP4
  • USB Playback Picture
  • BMP
  • GIF
  • JPEG
  • JPG
  • USB Playback Video
  • M2TS
  • M4V
  • MK3D
  • MKV
  • MP4
  • MPEG
  • MPG
  • MTS
  • TS
  • TTS
  • VOB
  • WMV

  • Click here to view the manufacturer's item description/brochure

    ROHS Compliant

    Alternate MPNs: A8223391

    Weight: 47 lb

    Warranty: 3 Year Manufacturer

    Brand New

    Condition Levels Explained

    The product is brand new.

    3 Year Manufacturer Warranty

    Product Warranties Explained

    The product has a manufacturer warranty for the time period specified.
